1170 / 1410
1170
Prices in EURO - VAT not included
1170
END MILLS
13
8747
HSS-E-8%
Three-flute end mills, 45° bent. Short series. ISO 1641/2.
Central tang drive. Weldon shank. Cutting tolerance J14.
HSS-E COBALT 8%.
Ø
mm
6
8
10
12
14
16
18
Overall length
mm 57
69
72
83
83
92
92
Cutting edge length
mm 13
19
22
26
26
32
32
Drive Ø
mm 6
10
10
12
12
16
16
8747
Each 18,30 24,40 28,10 34,20 42,70 53,70 63,40
Ø
mm
20
Overall length
mm 104
Cutting edge length
mm 38
Drive Ø
mm 20
8747
Each 69,50
vuoto
ENDMILLS
8748
HSS-E-5%
Two-flute end mills. Short series. DIN 326 D-UNI 8260 A-ISO 1641/2.
Central tang drive. Morse taper shank and threaded hole. Cutting tolerance e8.
HSS-E COBALT 5%
Ø
mm
10
15
16
18
20
22
24
Overall length
mm 85
104
107
107
110
132
136
Cutting edge length
mm 13
16
19
19
22
22
26
Drive
C.M.
1
2
2
2
2
3
3
8748
Each 42,40 52,50 52,50 58,60 74,40 85,40 91,50
Ø
mm
25
30
32
Overall length
mm 136
136
171
Cutting edge length
mm 26
26
32
Drive
C.M.
3
3
4
8748
Each 92,70 114,00 144,00
Size mm 10 is running out of stock
vuoto
ENDMILLS
8748E
HSS-E-8%
Product description as Art. 8748
HSS-E COBALT 8%
Ø
mm
10
12
15
16
18
20
22
Overall length
mm 85
88
104
107
107
110
132
Cutting edge length
mm 13
16
16
19
19
22
22
Drive
C.M.
1
1
2
2
2
2
3
8748E
Each 13,80 13,90 59,80 59,80 67,10 84,10 96,30
Ø
mm
24
25
30
32
Overall length
mm 136
136
136
171
Cutting edge length
mm 26
26
26
32
Drive
C.M.
3
3
3
4
8748E
Each 105,00 107,00 131,00 167,00
Sizes mm 10 and 12 are running out of stock
vuoto
ENDMILLS
8749
HSS-E-5%
Three-flute end mills. Normal series. DIN 845 B- UNI 8250 – ISO 1641/2.
Central tang drive. Morse taper shank and threaded hole. Cutting tolerance e8.
HSS-E COBALT 5%
Ø
mm
14
15
16
18
20
22
24
Overall length
mm 117
117
117
117
123
140
147
Cutting edge length
mm 32
32
32
32
38
38
45
Drive
C.M.
2
2
2
2
2
3
3
8749
Each 17,90 65,90 65,90 67,10 85,40 91,50 104,00
Ø
mm
25
30
32
Overall length
mm 147
147
178
Cutting edge length
mm 45
45
53
Drive
C.M.
3
3
4
8749
Each 105,00 132,00 176,00
Size mm 14 is running out of stock
vuoto
ENDMILLS
8749F
HSS-E-8%
Product description as Art. 8749
HSS-E COBALT 8%
Ø
mm
15
16
18
20
22
24
25
Overall length
mm 117
117
117
123
140
147
147
Cutting edge length
mm 32
32
32
38
38
45
45
Drive
C.M.
2
2
2
2
3
3
3
8749F
Each 74,40 74,40 75,60 96,30 104,00 120,00 121,00
Ø
mm
30
32
Overall length
mm 147
178
Cutting edge length
mm 45
53
Drive
C.M.
3
4
8749F
Each 152,00 202,00
vuoto
ENDMILLS
