1168 / 1410
1168
Prices in EURO - VAT not included
1168
END MILLS
13
END MILLS
8732
HSS-E-8%
Prod. SCU
Two-flute end mills. Short series. DIN 327 B – UNI 8254 A-ISO 1641/1.
Central tang drive. Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%
Ø
mm
2
2,5
3
3,5
4
4,5
5
5,5
Overall length
mm 48
48
49
49
51
51
52
52
Cutting edge length
mm 4
4
5
5
7
7
8
8
Drive Ø
mm 6
6
6
6
6
6
6
6
8732
Each 11,90 11,90 11,90 11,90 11,90 11,90 11,90 11,90
Ø
mm
6
6,5
7
7,5
8
8,5
9
9,5
Overall length
mm 52
60
60
60
61
61
61
61
Cutting edge length
mm 8
10
10
10
11
11
11
11
Drive Ø
mm 6
10
10
10
10
10
10
10
8732
Each 11,90 17,10 17,10 17,10 17,10 17,10 17,10 17,10
Ø
mm
10
11
12
13
14
15
16
17
Overall length
mm 63
70
73
73
73
73
79
79
Cutting edge length
mm 13
13
16
16
16
16
16
19
Drive Ø
mm 10
12
12
12
12
12
16
16
8732
Each 17,10 22,70 22,70 25,10 25,10 29,20 30,70 37,90
Ø
mm
18
19
20
22
25
30
Overall length
mm 79
79
88
88
102 102
Cutting edge length
mm 19
19
22
22
26
26
Drive Ø
mm 16
16
20
20
25
25
8732
Each 37,90 45,10 45,10 50,40 72,40 123,00
vuoto
ENDMILLS
8734
TiAIN
HSS-E-8%
Product description as Art. 8732
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 51
52
52
61
63
73
73
Cutting edge length
mm 7
8
8
11
13
16
16
Drive Ø
mm 6
6
6
10
10
12
12
8734
Each 13,50 13,50 13,50 19,40 19,40 25,70 36,60
Ø
mm
16
18
20
Overall length
mm 79
79
88
Cutting edge length
mm 16
19
22
Drive Ø
mm 16
16
20
8734
Each 44,20 54,20 68,80
vuoto
ENDMILLS
8737
HSS-E-8%
Two-flute end mills. Long series. ISO 1641/1. Central tang drive.
Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 56
63
68
68
88
95
110
Cutting edge length
mm 8
11
13
13
19
22
26
Drive Ø
mm 6
6
6
6
10
10
12
8737
Each 15,40 15,40 15,40 15,40 21,50 21,50 28,70
Ø
mm
14
16
18
20
Overall length
mm 110
123
123
141
Cutting edge length
mm 26
32
32
38
Drive Ø
mm 12
16
16
20
8737
Each 32,80 40,10 49,60 58,90
vuoto
ENDMILLS
8738
HSS-E-8%
Two-flute, ball nose end mills. Short series. ISO 1641/1.
Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
10
Overall length
mm 49
51
52
52
60
61
61
63
Cutting edge length
mm 5
7
8
8
10
11
11
13
Drive Ø
mm 6
6
6
6
10
10
10
10
8738
Each 17,70 17,70 17,70 17,70 22,50 22,50 22,50 22,50
Ø
mm
11
12
13
14
15
16
18
20
Overall length
mm 70
73
73
73
73
79
79
82
Cutting edge length
mm 13
16
16
16
16
19
19
22
Drive Ø
mm 12
12
12
12
12
16
16
20
8738
Each 29,20 29,20 33,10 33,10 37,10 38,30 47,30 54,10
vuoto
ENDMILLS
