1174 / 1410
1174
Prices in EURO - VAT not included
1174
SHELL-END MILLS
13
8762E
HSS-E-8%
Four-flute end mills for SEMI-FINISHING. Long series.
Weldon shank. Cutting tolerance J14.
HSS-E COBALT 8%
Ø
mm
8
10
12
14
15
16
18
Overall length
mm 88
95
110
110
110
123
123
Cutting edge length
mm 38
45
53
53
53
63
63
Drive Ø
mm 10
10
12
12
16
16
16
8762E
Each 49,80 49,80 57,60 80,60 89,10 84,40 96,10
Ø
mm
20
22
Overall length
mm 141
151
Cutting edge length
mm 75
75
Drive Ø
mm 20
20
8762E
Each 106,00 146,00
vuoto
SHELL-ENDMILLS
8763
HSS-E-5%
Spiral flute end mills for SEMI-FINISHING. Short series.
DIN 845 B – UNI 8250 – ISO 1641/2. Morse taper shank and threaded hole.
Cutting tolerance J14.
Ø 16 to 22mm=4 flute/Ø 24 to 32mm=5 flute
HSS-E COBALT 5%
Ø
mm
16
18
20
22
24
26
28
Overall length
mm 117
117
123
140
147
147
147
Cutting edge length
mm 32
32
38
38
45
45
45
Drive
C.M.
2
2
2
3
3
3
3
8763
Each 70,70 78,10 85,40 102,00 113,00 126,00 139,00
Ø
mm
30
32
Overall length
mm 147
178
Cutting edge length
mm 45
53
Drive
C.M.
3
4
8763
Each 159,00 196,00
vuoto
SHELL-ENDMILLS
8764
HSS-E-8%
Product description as Art. 8763
HSS-E COBALT 8%
Ø
mm
16
18
20
22
24
26
28
Overall length
mm 117
117
123
140
147
147
147
Cutting edge length
mm 32
32
38
38
45
45
45
Drive
C.M.
2
2
2
3
3
3
3
8764
Each 82,90 91,50 102,00 116,00 130,00 141,00 155,00
Ø
mm
30
32
Overall length
mm 147
178
Cutting edge length
mm 45
53
Drive
C.M.
3
4
8764
Each 171,00 225,00
vuoto
SHELL-ENDMILLS
8766
HSS-E-8%
Spiral flute end mills for ROUGHING. Short series.
DIN 844 A – UNI 8244 A – ISO 1641/1. Weldon shank. Cutting tolerance J14.
Ø mm 6 = 3 flute / Ø mm 8 a 22 = 4 flute / Ø mm 25-30 = 5 flute.
HSS-E COBALT 8%
Ø
mm
6
8
10
12
14
15
16
Overall length
mm 57
69
72
83
83
83
92
Cutting edge length
mm 13
19
22
26
26
26
32
Drive Ø
mm 6
10
10
12
12
12
16
8766
Each 29,80 31,70 31,70 35,40 44,90 47,90 50,10
Ø
mm
18
20
22
25
30
Overall length
mm 92
104
104
121
121
Cutting edge length
mm 32
38
38
45
45
Drive Ø
mm 16
20
20
25
25
8766
Each 52,80 60,80 76,60 92,50 138,00
When the stocks will be run out, Ø 15 mm will have the connection Ø 16 mm.
vuoto
SHELL-ENDMILLS
8766E
HSS-E-8%
TiAIN
Spiral flute end mills for ROUGHING. Short series.
DIN 844 A – UNI 8244 A – ISO 1641/1. Weldon shank. Cutting tolerance J14.
Ø 6 to 22mm=4 flute/Ø 25-30mm=5 flute
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
10
12
14
16
18
20
Overall length
mm 72
83
83
92
92
104
Cutting edge length
mm 22
26
26
32
32
38
Drive Ø
mm 10
12
12
16
16
20
8766E
Each 36,20 40,40 59,80 66,60 71,40 86,70
vuoto
