1169 / 1410
1169
Prices in EURO - VAT not included
1169
END MILLS
13
8738E
HSS-E-8%
TiAIN
Product description as Art. 8738
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 51
52
52
61
63
73
73
Cutting edge length
mm 7
8
8
11
13
16
16
Drive Ø
mm 6
6
6
10
10
12
12
8738E
Each 20,20 20,20 20,20 25,60 25,60 33,50 45,40
Ø
mm
16
18
20
Overall length
mm 79
79
82
Cutting edge length
mm 19
19
22
Drive Ø
mm 16
16
20
8738E
Each 52,70 63,90 74,70
vuoto
ENDMILLS
8739
HSS-E-8%
Two-flute, ball nose end mills. Long series. ISO 1641/1.
Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%.
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 56
63
68
68
88
95
110
Cutting edge length
mm 8
11
13
13
19
22
26
Drive Ø
mm 6
6
6
6
10
10
12
8739
Each 21,90 21,90 21,90 21,90 28,10 28,10 36,80
Ø
mm
14
16
18
20
Overall length
mm 110
123
123
141
Cutting edge length
mm 26
32
32
38
Drive Ø
mm 12
16
16
20
8739
Each 42,50 49,80 61,40 70,90
vuoto
ENDMILLS
8742
HSS-E-8%
Three-flute end mills. Short series. DIN 844 A-UNI 8244 A-ISO 1641/1.
Central tang drive. Weldon shank. Cutting tolerance e8
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
Overall length
mm 52
55
57
57
66
69
69
Cutting edge length
mm 8
11
13
13
16
19
19
Drive Ø
mm 6
6
6
6
10
10
10
8742
Each 14,10 14,10 14,10 14,10 18,80 18,80 18,80
Ø
mm
10
11
12
13
14
15
16
Overall length
mm 72
79
83
83
83
83
92
Cutting edge length
mm 22
22
26
26
26
26
32
Drive Ø
mm 10
12
12
12
12
12
16
8742
Each 18,80 25,10 25,10 30,10 27,50 32,00 33,60
Ø
mm
18
20
22
Overall length
mm 92
104
104
Cutting edge length
mm 32
38
38
Drive Ø
mm 16
20
20
8742
Each 41,60 49,70 55,30
vuoto
ENDMILLS
8743
HSS-E-8%
TiAIN
Product description as Art. 8742
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 55
57
57
69
72
83
83
Cutting edge length
mm 11
13
13
19
22
26
26
Drive Ø
mm 6
6
6
10
10
12
12
8743
Each 21,80 21,80 21,80 31,10 31,90 40,40 44,70
Ø
mm
16
18
20
Overall length
mm 92
92
104
Cutting edge length
mm 32
32
38
Drive Ø
mm 16
16
20
8743
Each 53,20 65,50 82,90
vuoto
ENDMILLS
8746
HSS-E-8%
Three-flute end mills. Long series. DIN 8245 A--ISO 1641/1.
Central tang drive. Weldon shank. Cutting tolerance e8
HSS-E COBALT 8%
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 56
63
68
68
88
95
110
Cutting edge length
mm 12
19
24
24
38
45
53
Drive Ø
mm 6
6
6
6
10
10
12
8746
Each 18,10 18,10 18,10 18,10 25,30 25,30 33,70
Ø
mm
14
16
18
20
Overall length
mm 110
123
123
141
Cutting edge length
mm 53
63
63
75
Drive Ø
mm 12
16
16
20
8746
Each 38,50 47,10 58,30 69,50
vuoto
ENDMILLS
