SHELL-END MILLS
13
SHELL-END MILLS
8751
HSS-E-8%
Prod. SCU
Spiral flute end mills. Short series. DIN 844 A - UNI 8244 - ISO 1641/1.
Weldon shank. Cutting tolerance J14.
Ø 3 to 22mm = 4 flute/Ø 25 and 28mm = 5 flute/Ø 30mm = 6 flute
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
10
Overall length
mm 52
55
57
57
66
69
69
72
Cutting edge length
mm 8
11
13
13
16
19
19
22
Drive Ø
mm 6
6
6
6
10
10
10
10
8751
Each 14,10 14,10 14,10 14,10 18,80 18,80 18,80 18,80
Ø
mm
11
12
13
14
15
16
17
18
Overall length
mm 79
83
83
83
83
92
92
92
Cutting edge length
mm 22
26
26
26
26
32
32
32
Drive Ø
mm 12
12
12
12
16
16
16
16
8751
Each 26,30 26,30 28,90 28,90 33,50 33,60 35,40 43,70
Ø
mm
19
20
22
25
28
30
Overall length
mm 92
104 104 121 121 121
Cutting edge length
mm 32
38
38
45
45
45
Drive Ø
mm 20
20
20
25
25
25
8751
Each 43,50 51,90 57,90 83,20 92,70 97,40
When the stocks will be run out, Ø 19 mm will have the connection Ø 16 mm.
vuoto
SHELL-ENDMILLS
8751E
HSS-E-8%
TiAIN
Product description as Art. 8751
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 55
57
57
69
72
83
83
Cutting edge length
mm 11
13
13
19
22
26
26
Drive Ø
mm 6
6
6
10
10
12
12
8751E
Each 15,90 15,90 15,90 21,50 21,50 30,10 41,60
Ø
mm
16
18
20
Overall length
mm 92
92
104
Cutting edge length
mm 32
32
38
Drive Ø
mm 16
16
20
8751E
Each 49,50 61,10 76,60
vuoto
SHELL-ENDMILLS
8753
HSS-E-8%
Four-flute end mills. Long series. UNI 8245 A-ISO 1641/1.
Weldon shank. Cutting tolerance J14.
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
Overall length
mm 56
63
68
68
80
88
88
Cutting edge length
mm 12
19
24
24
30
38
38
Drive Ø
mm 6
6
6
6
10
10
10
8753
Each 18,10 18,10 18,10 18,10 25,30 25,30 25,30
Ø
mm
10
11
12
13
14
15
16
Overall length
mm 95
102
110
110
110
110
123
Cutting edge length
mm 45
45
53
53
53
53
63
Drive Ø
mm 10
12
12
12
12
16
16
8753
Each 25,30 35,50 35,50 40,50 40,50 46,80 49,50
Ø
mm
17
18
19
20
22
Overall length
mm 123
123
123
141
151
Cutting edge length
mm 63
63
63
75
75
Drive Ø
mm 16
16
20
20
20
8753
Each 61,10 61,10 72,60 72,90 81,10
vuoto
SHELL-ENDMILLS
8755
HSS-E-5%
Spiral flute end mills. Short series. DIN 845 B - UNI 8250 - ISO 1641/2.
Morse taper shank and threaded hole. Cutting tolerance J14.
Ø 12 to 22mm = 4 flute/Ø 24 and 25mm = 5 flute/Ø 30 and 32mm = 6 flute
HSS-E COBALT 5%
Ø
mm
14
15
16
18
20
22
24
Overall length
mm 117
117
117
117
123
140
147
Cutting edge length
mm 32
32
32
32
38
38
45
Drive
C.M.
2
2
2
2
2
3
3
8755
Each 52,50 52,50 52,50 56,10 59,80 76,80 82,90
Ø
mm
25
30
32
Overall length
mm 147
147
178
Cutting edge length
mm 45
45
53
Drive
C.M.
3
3
4
8755
Each 85,40 119,00 142,00
Size Ø 32mm has no cutting edge in the middle.
