1175 / 1410
1175
Prices in EURO - VAT not included
1175
SHELL-END MILLS
13
8768
HSS-E-8%
Spiral flute end mills for ROUGHING. Long series.
Weldon shank. Cutting tolerance J14.
Ø 8 to 22mm=4 flute/Ø 25mm=5 flute
HSS-E COBALT 8%
Ø
mm
8
10
12
14
15
16
18
Overall length
mm 88
95
110
110
110
123
123
Cutting edge length
mm 38
45
53
53
53
63
63
Drive Ø
mm 10
10
12
12
12
16
16
8768
Each 41,60 41,70 47,90 67,20 70,30 70,40 79,90
Ø
mm
20
22
25
Overall length
mm 141
151
166
Cutting edge length
mm 75
75
90
Drive Ø
mm 20
20
25
8768
Each 87,90 122,00 135,00
When the stocks will be run out, Ø 15 mm will have the connection Ø 16 mm.
vuoto
SHELL-ENDMILLS
8770
HSS-E-5%
Spiral flute end mills for ROUGHING. Short series. DIN 845 B – UNI 8250- ISO 1641/2. Morse
taper shank and threaded hole. Cutting tolerance J14.
Ø 16 to 22mm=4 flute/Ø 24 to 32mm=5 flute
HSS-E COBALT 5%
Ø
mm
16 18 20 22 24 26 28 30 32
Overall length
mm 117 117 123 140 147 147 147 147 178
Cutting edge length
mm 32 32 38 38 45 45 45 45 53
Drive
C.M.
2
2
2
3
3
3
3
3
4
8770
Each 70,70 78,10 85,40 102,00 113,00 126,00 139,00 159,00 196,00
vuoto
SHELL-ENDMILLS
8771
HSS-E-8%
Product description as Art. 8770
HSS-E COBALT 8%
Ø
mm
16 18 20 22 24 26 28 30 32
Overall length
mm 117 117 123 140 147 147 147 147 178
Cutting edge length
mm 32 32 38 38 45 45 45 45 53
Drive
C.M.
2
2
2
3
3
3
3
3
4
8771
Each 82,90 91,50 102,00 116,00 130,00 141,00 155,00 171,00 225,00
vuoto
SHELL-ENDMILLS
8775
HSS-E-8%
Four-flute end mills for ROUGHING, fine pitch. Short series.
DIN 844 A – UNI 8244A – ISO 1641/1. HSS-E COBALT 8%. Weldon shank. Cutting tolerance
J14. For finer surface finish.
Ø
mm
10
12
14
15
16
18
20
22
Overall length
mm 72
83
83
83
92
92
104 104
Cutting edge length
mm 22
26
26
26
32
32
38
38
Drive Ø
mm 10
12
12
12
16
16
20
20
8775
Each 34,80 38,80 49,30 53,10 55,30 58,10 66,80 84,30
When the stocks will be run out, Ø 15 mm will have the connection Ø 16 mm.
vuoto
SHELL-ENDMILLS
8779
HSS-E-5%
Reinforced helical teeth. N type. DIN 1880 – UNI 3903 – ISO 2586.
HSS-E COBALT 5%.
Longitudinal and transversal driving slot. Cutting tolerance J16.
Ø
mm
40
50
63
80
Thickness
mm 32
36
40
45
Bore Ø
mm 16
22
27
27
Teeth
Nr
8
8
8
10
8779
Each 107,00 137,00 188,00 323,00
vuoto
SHELL-ENDMILLS
8781
HSS-E-5%
Shell mills, reinforced helical teeth. N type. DIN 841.
HSS-E COBALT 5%.
Longitudinal driving slot. Cutting tolerance J16.
Ø
mm
30
35
40
50
60
75
Thickness
mm 30
35
40
50
60
75
Bore Ø
mm 13
16
16
22
27
27
Teeth
Nr
6
6
8
8
8
10
8781
Each 108,00 116,00 141,00 211,00 284,00 516,00
vuoto
SHELL-ENDMILLS
