1148 / 1410
1148
Prices in EURO - VAT not included
1148
REINFORCED CENTRE DRILLS
13
REINFORCED CENTRE DRILLS
8603G
HSS
Orig. Hartner - Art. 83200
DIN 333. Form A. Reinforced type. Cutting angle 118°.
HSS. For drilling metals and steel. Right-hand cutting.
With protective chamfer.
60°/120° countersink taper.
Two working processes with one single operation.
Tip Ø
mm
1,6
2
2,5
3,15
4
5
6,3
Body Ø
mm 6,3
8
10
11,2
14
18
20
Overall length
mm 45
50
56
60
67
75
80
8603G
Each 15,40 17,10 20,70 30,20 38,40 48,10 77,70
vuoto
REINFORCEDCENTREDRILLS
CENTRE DRILLS
8606G
HSS
Orig. Hartner - Art. 83000
DIN 333. Form R. Radius type. Cutting angle 118°.
HSS.
For drilling metal and steel. Right-hand cutting.
For creating arc countersinks, with progressive taper up to 60°.
Tip Ø
mm
1
1,25
1,6
2
2,5
3,15
4
Body Ø
mm 3,15
3,15
4
5
6,3
8
10
Overall length
mm 31,5
31,5
35,5
40
45
50
56
8606G
Each 9,50 11,40 9,02
9,12 10,90 14,70 20,20
Tip Ø
mm
5
6,3
Body Ø
mm 12,5
16
Overall length
mm 63
71
8606G
Each 30,70 45,60
vuoto
CENTREDRILLS
CENTRE DRILLS WITH FLATTED BODY
8608G
HSS
Orig. Hartner - Art. 83600
DIN 333. Form A. Cutting angle 118°.
With flatted body. HSS
For drilling metals and steel. Right-hand cutting.
60° countersink taper.
Tip Ø
mm
1,6
2
2,5
3,15
4
5
6,3
Body Ø
mm 4
5
6,3
8
10
12,5
16
Overall length
mm 35,5
40
45
50
56
63
71
8608G
Each 16,90 14,10 15,50 18,70 26,40 44,60 74,80
vuoto
CENTREDRILLSWITHFLATTEDBODY
8609G
HSS
Orig. Hartner - Art. 83700
DIN 333. Form B. Reinforced type. Cutting angle 118°.
With flatted body. HSS.
For drilling metal and steel. Right-hand cutting.
With protective chamfer. 60°/120° countersink taper.
Two working processes with one single operation.
Tip Ø
mm
1,6
2
2,5
3,15
4
Body Ø
mm 6,3
8
10
11,2
14
Overall length
mm 45
50
56
60
67
8609G
Each 20,70 23,50 28,30 40,80 48,10
Size mm 1,6 is running out of stock
vuoto
CENTREDRILLSWITHFLATTEDBODY
8610G
HSS
Orig. Hartner - Art. 83500
DIN 333. Form R. Radius type. Cutting angle 118°.
With flatted body. HSS.
For drilling metal and steel. Right-hand cutting.
For creating arch countersinks, with progressive taper up to 60°.
Tip Ø
mm
1,6
2
2,5
3,15
4
5
6,3
Body Ø
mm 4
5
6,3
8
10
12,5
16
Overall length
mm 35,5
40
45
50
56
63
71
8610G
Each 13,60 13,40 14,60 18,70 26,40 38,90 68,10
vuoto
CENTREDRILLSWITHFLATTEDBODY
TANGED STRAIGHT SHANK SPOTTING DRILLS, RIGHT HAND CUTTING
8612G
HSS
Orig. Hartner - Art. 81191
Type N. EXTRA-SHORT pattern.
HSS.
Very short spiral flute. It replaces pre-holes obtained by using drill bushes.
Perfect centring also on inclined surfaces.
Cylindrical shank.
With 120° cutting angle.
Ø
mm
3
4
5
6
8
10 12 16 20
Helix length
mm 12 12 14 16 21 25 30 37 45
Overall length
mm 46 55 62 66 79 89 102 115 131
8612G
Each 14,10 13,80 15,10 14,70 24,50 27,60 40,10 51,70 83,70
vuoto
TANGEDSTRAIGHTSHANKSPOTTINGDRILLS,RIGHTHANDCUTTING
