1145 / 1410
1145
Prices in EURO - VAT not included
1145
STRAIGHT SHANK SUBLAND DRILLS 180° INCLUDED ANGLE,, RIGHT HAND CUTTING
13
STRAIGHT SHANK SUBLAND DRILLS 180° INCLUDED ANGLE,, RIGHT HAND CUTTING
8546G
HSS
Orig. Hartner - Art. 85210
DIN 8376. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spriral flute for drilling.
180° flat stepped bigger spiral flute.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
Guide tip Ø d
mm 3,4
4,5
5,5
6,6
9
11
Countersink D Ø
mm 6
8
10
11
15
18
Guiding spiral I length
mm 9
11
13
15
19
23
Spiral total length.
mm 57
75
87
94
114
130
Overall length
mm 93
117
133
142
169
191
8546G
Each 48,10 50,80 61,40 71,10 89,20 196,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS180° INCLUDEDANGLE,,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
8552G
HSS
Orig. Hartner - Art. 85916
Type N. HSS. Cutting angle 118°.
90° countersinking angle for countersink-head screw seats. FINE tolerance.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
Guide tip Ø d
mm 3,2
4,3
5,3
6,4
8,4
10,5
Countersink D Ø
mm 6
8
10
11,5
15
19
Guiding spiral I length
mm 9
11
13
15
19
23
Spiral total length.
mm 28
37
43
47
56
64
Overall length
mm 66
79
89
95
111
127
8552G
Each 30,70 34,10 43,70 54,70 69,10 110,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS90° INCLUDEDANGLE,RIGHTHANDCUTTING
8553G
HSS
Orig. Hartner - Art. 85917
Type N. HSS. Cutting angle 118°.
90° countersinking angle for countersink-head screw seats. MEDIUM tolerance.
Cylindrical shank.
For screws
M.
3
4
5
6
8
Guide tip Ø d
mm 3,4
4,5
5,5
6,6
9
Countersink D Ø
mm 6,6
9
11
13
17,2
Guiding spiral I length
mm 9
11
13
15
19
Spiral total length.
mm 31
40
47
51
62
Overall length
mm 70
84
95
102
123
8553G
Each 34,10 36,90 50,80 60,40 102,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS90° INCLUDEDANGLE,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
8558G
HSS
Orig. Hartner - Art. 85010
DIN 8374. Type N. HSS. Cutting angle 118°. With independent flutes.
Small spiral flute for drilling. Bigger spiral flute with 90° countersinking angle for countersink-head
screw seats. FINE tolerance. Cylindrical shank.
For screws
M.
3
4
5
6
8
Guide tip Ø d
mm 3,2
4,3
5,3
6,4
8,4
Countersink D Ø
mm 6
8
10
11,5
15
Guiding spiral I length
mm 9
11
13
15
19
Spiral total length.
mm 57
75
87
94
114
Overall length
mm 93
117
133
142
169
8558G
Each 47,10 54,70 67,10 81,50 146,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS90° INCLUDEDANGLE,RIGHTHANDCUTTING
8559G
HSS
Orig. Hartner - Art. 85110
DIN 8374. Type N. HSS. Cutting angle 118°. With independent flutes.
Small spiral flute for drilling. Bigger spiral flute with 90° countersinking angle for countersink-head
screw seats. MEDIUM tolerance. Cylindrical shank.
For screws
M.
3
4
5
6
8
Guide tip Ø d
mm 3,4
4,5
5,5
6,6
9
Countersink D Ø
mm 6,6
9
11
13
17,2
Guiding spiral I length
mm 9
11
13
15
19
Spiral total length.
mm 63
81
94
101
130
Overall length
mm 101
125
142
151
191
8559G
Each 57,60 69,10 77,70 117,00 217,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS90° INCLUDEDANGLE,RIGHTHANDCUTTING
