1149 / 1410
1149
Prices in EURO - VAT not included
1149
TANGED STRAIGHT SHANK SPOTTING DRILLS, RIGHT HAND CUTTING
13
8613G
HSS
Orig. Hartner - Art. 81192
Product description as Art. 8612G
With 90° cutting angle.
Ø
mm
3
4
5
6
8
10
12
Helix length
mm 12
12
14
16
21
25
30
Overall length
mm 46
55
62
66
79
89
102
8613G
Each 14,10 13,80 14,30 14,70 24,50 27,60 40,10
Ø
mm
16
20
Helix length
mm 37
45
Overall length
mm 115
131
8613G
Each 51,70 83,70
TANGEDSTRAIGHTSHANKSPOTTINGDRILLS,RIGHTHANDCUTTING
TUNGSTEN-CARBIDE STUB DRILLS, RIGHT HAND CUTTING
8615G
HARTMETALL
Orig. Hartner - Art. 89242
Type N. EXTRA-SHORT pattern.
SOLID CARBIDE up to 10mm.
For manganese high-resistance steel, cast iron, aluminium alloys with high silicium content and
difficult to chip materials.
Cylindrical shank.
With 120° cutting angle.
Ø
mm
5
6
8
10
12
16
20
Helix length
mm 14
16
21
25
30
37
45
Overall length
mm 62
66
79
89
102
115
131
8615G
Each 38,40 41,10 64,40 91,10 123,00 226,00 380,00
TUNGSTEN-CARBIDESTUBDRILLS,RIGHTHANDCUTTING
8616G
HARTMETALL
Orig. Hartner - Art. 89243
Product description as Art. 8615G
With 90° cutting angle.
Ø
mm
5
6
8
10
12
16
20
Helix length
mm 14
16
21
25
30
37
45
Overall length
mm 62
66
79
89
102
115
131
8616G
Each 35,80 39,70 60,50 87,20 118,00 216,00 367,00
TUNGSTEN-CARBIDESTUBDRILLS,RIGHTHANDCUTTING
STUB DRILLS FOR SPOT WELDS
8616GT
TIN
HSS-E
Prod. SCU
EXTRA-SHORT type (SPOLTE-DRILL), self-centring. COBALT HSS-E, TIN coating.
For welding points and beads.
Special shank to fit pneumatic equipment.
Ø 8mm, overall length 40mm.
8616GT
Each 13,80
STUBDRILLSFORSPOTWELDS
8617G
HSS-E
EXTRA-SHORT type, self-centring. COBALT HSS-E.
For welding points and beads.
To be used also with hand drills.
Cylindrical shank. RIGHT-HAND rotation.
Ø
mm
6
7
8
10
Overall length
mm 66
74
79
89
8617G
Each 6,78
7,92
9,08 15,10
STUBDRILLSFORSPOTWELDS
8617GA
HSS-E
TIN
EXTRA-SHORT type, self-centring. COBALT HSS-E, TIN coating.
For welding points and beads.
To be used also with hand drills.
Cylindrical shank. RIGHT-HAND rotation.
Ø
mm
6
7
8
10
Overall length
mm 66
74
79
89
8617GA
Each 10,70 11,90 13,10 19,10
STUBDRILLSFORSPOTWELDS
DOUBLE END DRILLS, RIGHT HAND CUTTING
8617GE
HSS
Prod. SCU
Type N. Cutting angle 118°. HSS. BI-FRONT pattern.
For mechanics, carpenters, tinsmiths, for welding points and rivet applications.
To be used also with hand drills.
Cylindrical shank. RIGHT-HAND rotation. Packing unit: 10pcs, not sold separately.
Ø
mm
3
3,1
3,2 3,3
3,5
4
4,1
4,2
Helix length
mm 11
11
11
11
12
14
14
14
Overall length
mm 46
49
49
49
52
55
55
55
8617GE
Per pack 11,70 13,30 13,30 13,30 15,60 17,20 17,20 17,20
Ø
mm
4,5*
4,8
5
5,1
5,2 5,5*
6*
Helix length
mm 16
17
17
17
17
19
19
Overall length
mm 58
62
62
62
62
66
66
8617GE
Per pack 19,30 21,40 21,40 22,10 22,10 28,40 28,40
* Sizes running out of stock
DOUBLEENDDRILLS,RIGHTHANDCUTTING
