1152 / 1410
1152
Prices in EURO - VAT not included
1152
CORE DRILLS
13
8623G
HSS
Orig.Dürr - Art. 215-51
Product description as Art. 8622G
Helix with additional drain.
Effective broadening Ø mm
8
9
10
11
12
13
14
15
Pre-bore min Ø
mm 5,6 6,3
7
7,7 8,4 9,1 9,8 10,5
Helix length
mm 75
81
87
94 101 101 108 114
Overall length
mm 156 162 168 175 182 182 189 212
Drive
C.M.
1
1
1
1
1
1
1
2
8623G
Each 78,90 83,70 83,70 83,70 83,70 93,40 95,10 108,00
Effective broadening Ø mm
16
17
18
19
20
21
22
23
Pre-bore min Ø
mm 11,2 11,9 12,6 13,4 14
15
15
16
Helix length
mm 120 125 130 135 140 145 150 155
Overall length
mm 218 223 228 233 238 243 248 253
Drive
C.M.
2
2
2
2
2
2
2
2
8623G
Each 115,00 124,00 128,00 140,00 140,00 159,00 161,00 181,00
Effective broadening Ø mm
24
25
26
27
28
29
30
Pre-bore min Ø
mm 17
18
18
19
20
20
21
Helix length
mm 160 160 165 170 170 175 175
Overall length
mm 281 281 286 291 291 296 296
Drive
C.M.
3
3
3
3
3
3
3
8623G
Each 189,00 203,00 211,00 245,00 251,00 272,00 282,00
Attention: the optimal pre-hole must have a Ø 10% - 20% approx. smaller than
the real core drill Ø.
vuoto
COREDRILLS
MULTIPLEX SHANK HOLDERS, SHORT TYPE
8625G
Orig. Hartner - Art. 86612
SHORT type (for 3xD holes).
Made of steel, forced lubrication through internal cooling channels.
Rear feeding. Spiral flute.
CYLINDRICAL shank. RIGHT-HAND rotation.
With 2 screws.
Size
1
2
3
4
5
6
7
8
9
10
11
For plates Ø
mm 10-11,7 11,71-13,4 13,41-16,4 16,41-18,9 18,91-22,4 22,41-25,4 25,41-29 29,01-35 35,01-45 45,01-55 55,01-65
Drive Ø
mm 20
20
20
20
20
20
32
32
32
40
40
Overall length
mm 108
109
116
118
124
127
178
178
223
233
233
Helix length
mm 50
53
60
65
73
78
105
108
152
152
152
TORX screws size
M.
2x4
2x4
2,5x5
2,5x7
3x6
3x8
3,5x10 3,5x10
4x15
4x15
4x15
For plates thickness
mm 2,5
2,5
3,5
3,5
4
4
5
5
7
7
7
8625G
Each 366,00 366,00 403,00 403,00 440,00 440,00 524,00 524,00 675,00 698,00 742,00
For tool bits see Art. 8630 GT to 8633 G.
vuoto
MULTIPLEXSHANKHOLDERS,SHORTTYPE
MULTIPLEX SHANK HOLDERS, LONG TYPE
8625GL
Orig. Hartner - Art. 86622
LONG type (for 5xD holes).
Made of steel, forced lubrication through internal cooling channels.
Rear feeding. Spiral flute.
CYLINDRICAL shank. RIGHT-HAND rotation.
With 2 screws.
Size
1
2
3
4
5
6
7
8
9
10
11
Drive Ø
mm 20
20
20
20
20
20
32
32
32
40
40
For plates Ø
mm 10-11,7 11,71-13,4 13,41-16,4 16,41-18,9 18,91-22,4 22,41-25,4 25,41-29 29,01-35 35,01-45 45,01-55 55,01-65
Overall length
mm 140
150
160
170
180
180
240
240
280
290
290
Helix length
mm 83
94
104
117
129
131
166
170
210
210
210
TORX screws size
M.
2x4
2x4
2,5x5
2,5x7
3x6
3x8
3,5x10 3,5x10
4x15
4x15
4x15
For plates thickness
mm 2,5
2,5
3,5
3,5
4
4
5
5
7
7
7
8625GL
Each 383,00 383,00 440,00 440,00 440,00 440,00 470,00 557,00 614,00 651,00 698,00
For tool bits see Art. 8630 GT to 8633 G.
vuoto
MULTIPLEXSHANKHOLDERS,LONGTYPE
