1146 / 1410
1146
Prices in EURO - VAT not included
1146
STRAIGHT SHANK DRILLS FOR THREATED 60° CENTRE HOLES, RIGHT HAND CUTTING
13
STRAIGHT SHANK DRILLS FOR THREATED 60° CENTRE HOLES, RIGHT HAND CUTTING
8573G
HSS
Orig. Hartner - Art. 85912
DIN 1414. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spiral flute for drilling.
Bigger spiral flute with 60° countersinking angle.
Suitable for centerings to be threaded. To be used with automatic machines.
Cylindrical shank.
For screws
M.
4
5
6
8
10
12
Guide tip Ø
mm 3,3
4,2
5
6,8
8,5
10,2
Countersink Ø
mm 8
10
12,5
14
16
20
Spiral length
mm 23
27
33
41
47
59
Guide tip length
mm 11
13
16
19,5
23
28
Overall length
mm 63
67
71
88
94
105
8573G
Each 96,80 98,80 115,00 126,00 137,00 178,00
vuoto
STRAIGHTSHANKDRILLSFOR THREATED 60°CENTREHOLES,RIGHTHANDCUTTING
8575G
HSS
Orig. Hartner - Art. 85910
DIN 1414. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spiral flute for drilling. Bigger spiral flute with 60° countersinking
angle.
Suitable for centerings to be threaded. To be used with automatic machines. Cylindrical shank
with flat side surface and external lubrication channels.
For screws
M.
4
5
6
8
10
12
16
20
Guide tip Ø
mm 3,3
4,2
5
6,8
8,5 10,2 14 17,5
Countersink Ø
mm 8
10 12,5 14
16
20
25 31,5
Spiral length
mm 23
27
33
41
47
59
67
76
Guide tip length
mm 11
13
16 19,5 23
28
33
38
Overall length
mm 63
67
71
88
94
105 132 145
8575G
Each 107,00 116,00 126,00 120,00 137,00 179,00 252,00 340,00
vuoto
STRAIGHTSHANKDRILLSFOR THREATED 60°CENTREHOLES,RIGHTHANDCUTTING
8576G
HSS
Orig. Hartner - Art. 85911
DIN 1414. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spiral flute for drilling.
Bigger spiral flute with 60° countersinking angle, with rounded chamfer.
Suitable for for centerings to be threaded. To be used with automatic machines.
Cylindrical shank with flat side surface and external lubrication channels.
For screws
M.
4
5
6
8
10
16
Guide tip Ø
mm 3,3
4,2
5
6,8
8,5
14
Countersink Ø
mm 8
10
12,5
14
16
25
Spiral length
mm 23
27
33
41
47
67
Guide tip length
mm 11
13
16
19,5
23
33
Overall length
mm 63
67
71
88
94
132
8576G
Each 114,00 117,00 130,00 132,00 153,00 273,00
vuoto
STRAIGHTSHANKDRILLSFOR THREATED 60°CENTREHOLES,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 180° INCLUDED ANGLE,, RIGHT HAND CUTTING
8584G
HSS
Orig. Hartner - Art. 85610
DIN 8377. Type N. HSS.
Cutting angle 118°.
With independent flutes. Small spiral flute for drilling.
180° flat stepped bigger spiral flute.
Morse taper shank.
For screws
M.
5
6
8
10
12
14
16
20
Guide tip Ø d
mm 5,5
6,6
9
11 13,5 15,5 17,5 22
Countersink D Ø
mm 10
11
15
18
20
24
26
33
Guiding spiral I length
mm 13
15
19
23
27
31
35
43
Spiral total length.
mm 87
94
114 130 140 160 165 185
Overall length
mm 168 175 212 228 238 281 286 334
Drive
C.M.
1
1
2
2
2
3
3
4
8584G
Each 105,00 97,80 116,00 159,00 189,00 248,00 301,00 453,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS 180° INCLUDEDANGLE,,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
8587G
HSS
Orig. Hartner - Art. 85510
DIN 8375. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spiral flute for drilling.
Bigger spiral flute with 90° countersinking angle for countersink-head screw seats.
Morse taper shank.
For screws
M.
5
6
8
10
Guide tip Ø d
mm 5,5
6,6
9
11
Countersink D Ø
mm 11
13
17,2
21,5
Guiding spiral I length
mm 13
15
19
23
Spiral total length.
mm 94
101
130
150
Overall length
mm 175
182
228
248
Drive
C.M.
1
1
2
2
8587G
Each 136,00 121,00 157,00 244,00
Sizes M 5 - 6 - 10 are running out of stock
STRAIGHTSHANKSUBLANDDRILLS 90° INCLUDEDANGLE,RIGHTHANDCUTTING
