1151 / 1410
1151
Prices in EURO - VAT not included
1151
TAPER PIN TWIST DRILLS
13
8619GP
HSS
Orig. Dürr - Art. 121-41
Product description as Art. 8619GE
Morse taper shank. RIGHT-HAND rotation.
Rated Ø
mm
16
20
25
Helix length
mm 230 260 362
Overall length
mm 330 393 430
Drive
C.M.
2
3
3
8619GP
Each 449,00 638,00 927,00
For conical reamers for plugs see Art. 8954 G and Art. 8968 G.
vuoto
TAPERPINTWISTDRILLS
CORE DRILLS
8620G
HSS
Orig. Hartner - Art. 86010
DIN 344 – Type N.
HSS.
3-fluted type.
For enlarging holes previously obtained, through drilling, punching and fusion.
The drill is not able to make holes from full load.
Cylindrical drive shank. RIGHT-HAND rotation.
Effective broadening Ø mm
4,8
5,8
6
6,8*
8*
9,8
10
10,7*
11,75
12
13
Pre-bore min Ø
mm 3,5
4,2
4,2
4,9
5,6
7
7
7,7
8,4
8,4
9,1
Helix length
mm 74
80
80
93
100
116
116
125
134
134
134
Overall length
mm 108
116
116
133
142
162
162
173
184
184
184
8620G
Each 29,80
31,20
26,40
33,10
37,90
43,70
44,10
84,10
58,50
55,60
66,20
Attention: the optimal pre-hole must have a Ø 10% - 20% approx. smaller than the real core drill Ø.
* Sizes running out of stock
COREDRILLS
8621G
HSS
Orig.Dürr - Art. 215-21
Product description as Art. 8620G
Helix with additional drain.
Effective broadening Ø mm
5
6
7
8
9
10 11 12 13 14 15 16 17 18 19 20
Pre-bore min Ø
mm 3,5 4,2 4,9 5,6 6,3
7
7,7 8,4 9,1 9,8 10,5 11,2 11,8 12,5 13,2 14
Helix length
mm 74 80 93 100 107 116 125 134 134 142 147 153 159 165 171 177
Overall length
mm 108 116 133 142 151 162 173 184 184 194 202 211 218 226 234 242
8621G
Each 41,90 43,50 46,70 56,40 65,20 67,60 86,10 82,10 102,00 121,00 132,00 142,00 184,00 186,00 203,00 214,00
Attention: the optimal pre-hole must have a Ø 10% - 20% approx. smaller than the real core drill Ø.
vuoto
COREDRILLS
8622G
HSS
Orig. Hartner - Art. 86110
DIN 343 – Type N.
HSS.
3-fluted type.
For enlarging holes previously obtained, through drilling, punching and fusion.
The drill is not able to make holes from full load.
Morse taper shank. RIGHT-HAND rotation.
Effective broadening Ø mm
13,75 14 15,75 16,75 17 17,75 18
19,7
20
21
22
24
25
26
Pre-bore min Ø
mm 9,8
9,8 11,2 11,9 11,9 12,6 12,6
14
14
14,6 15,3 16,6 17,3
18
Helix length
mm 108 108 120 125 125 130 130 140 140 145 150 160 160 165
Overall length
mm 189 189 218 223 223 228 228 238 238 243 248 281 281 286
Drive
C.M.
1
1
2
2
2
2
2
2
2
2
2
3
3
3
8622G
Each 71,10 64,30 75,80 91,10 78,60 86,30 80,60 90,10 79,60 106,00 106,00 123,00 117,00 133,00
Attention: the optimal pre-hole must have a Ø 10% - 20% approx. smaller than the real core drill Ø.
