Prices in EURO - VAT not included
674
CLAMPING DEVICES
9
2829E
Threaded pins (stud bolts) DIN 6379.
Thread.(D) x length (L) Mxmm
6x40 6x60 6x80 8x40 8x63 8x80 8x125 10x50
Thread (B) length
mm 20
37
60
20
40
50
75
25
2829E
Each 0,78 0,84 1,14 0,96 1,04 1,34 1,90 1,18
Thread.(D) x length (L) Mxmm
10x80 10x100 10x160 12x63 12x80 12x125 12x200 14x63
Thread (B) length
mm 50
75 100 32
50
75 125 32
2829E
Each 1,38 1,72 2,38 1,86 2,02 2,40 3,02 1,88
Thread.(D) x length (L) Mxmm
14x100 14x160 14x200 16x100 16x160 16x200 16x250 18x80
Thread (B) length
mm 63 100 125 63 100 125 160 50
2829E
Each 2,14 3,00 3,50 2,68 4,02 4,72 4,86 2,68
Thread.(D) x length (L) Mxmm
18x160 18x200 20x125 20x160 20x200 20x250 22x100 22x160
Thread (B) length
mm 100 125 70 100 125 160 45 100
2829E
Each 4,18 4,86 4,02 4,86 5,70 6,70 4,18 6,02
Thread.(D) x length (L) Mxmm
22x200 22x250 24x160 24x200 24x250
Thread (B) length
mm 125 160 100 125 160
2829E
Each 6,70 8,36 6,36 7,36 9,04
vuoto
CLAMPINGDEVICES
2829F
Threaded plugs for T-nuts, square - DIN 508.
Type
6
8
10
12
12A 14
16
Thread (M)
M.
6
8
10
12
12
14
16
Size (GROOVE)
mm 8
10
12
14
16
16
18
Plug dimensions (AxB)
mm 13x10 15x12 18x14 22x16 25x18 25x18 28x20
Height (C)
mm 6
6
7
8
9
9
10
2829F
Each 2,14
2,30
2,54
2,80
3,44
3,48
4,40
Type
16A 18
20
22
24
Thread (M)
M.
16
18
20
22
24
Size (GROOVE)
mm 20
20
22
24
28
Plug dimensions (AxB)
mm 32x24 32x24 35x28 40x32 44x35
Height (C)
mm 12
12
14
16
18
2829F
Each 5,86
6,48
6,98 11,10 13,30
vuoto
CLAMPINGDEVICES
2829G
Plugs fot T-nuts, square, DIN 508 R.
Size (GROOVE)
8
10 12 14 16 18 20 22 24
Plug dimensions (AxB)
M.
13x10 15x12 18x14 22x16 25x18 28x20 32x24 35x28 40x32
Height "C"
mm 6
6
7
8
9
10 12 14 16
2829G
Each 1,52 1,52 1,68 2,02 2,52 3,02 4,18 5,36 8,36
vuoto
CLAMPINGDEVICES
2829L
Threaded plugs for T-nuts, rectangular
Thread (M)
M.
8
10
12
14
16
18
Size (GROOVE)
mm 10
12
14
16
18
20
Plug dimensions (AxLxB)
mm 15x30x12 18x36x14 22x44x16 25x50x18 28x56x20 32x64x24
Height (C)
mm 6
7
8
9
10
12
2829L
Each 3,34
3,68
5,36
6,02
7,54
10,40
Thread (M)
M.
20
22
24
Size (GROOVE)
mm 22
24
28
Plug dimensions (AxLxB)
mm 35x70x28 40x80x32 44x88x36
Height (C)
mm 14
16
18
2829L
Each 14,30
20,10
26,80
vuoto
CLAMPINGDEVICES
2829M
Threaded plugs for T-nuts, rhomboidal
Thread (M)
M.
10
12
14
16
18
20
24
Size (GROOVE)
mm 12
14
16
18
20
22
28
Plug dimensions (AxB)
mm 18x14 22x16 25x18 28x20 32x24 36x28 44x36
Height (C)
mm 7
8
9
10
12
14
18
2829M
Each 6,52
7,54
8,36
9,38 13,40 15,10 20,10
vuoto
CLAMPINGDEVICES
2829P
In special steel, hardened. Burnished.
Hexagon high nuts, lathed. DIN 6330 B.
Thread (M)
M.
6
8
10
12
14
16
18
Height x key opening (HxS) mm 8x9 12x13 15x17 18x19 21x22 24x24 27x27
2829P
Each 0,68
0,70
0,88
1,14
1,42
1,78
2,52
Thread (M)
M.
20
22
24
Height x key opening (HxS) mm 30x30 33x32 36x36
2829P
Each 3,00
4,12
5,24
vuoto
CLAMPINGDEVICES
2829R
Nuts for threaded pins.
Thread (M)
M.
6
8
10
12
14
16
18
Height x key opening (HxS) mm 18x10 24x13 30x17 36x19 42x22 48x24 54x27
2829R
Each 1,50
1,54
1,76
2,04
2,78
2,94
4,88
Thread (M)
M.
20
22
24
Height x key opening (HxS) mm 60x30 66x32 72x36
2829R
Each 5,28
7,14
9,06
vuoto
