CLAMPING DEVICES IN STAINLESS STEEL
9
CLAMPING DEVICES IN STAINLESS STEEL
2834GA
INOX
Prod. SCU - Orig. AMF
High quality safe clamping devices. Double lever operated to avoid release during clamping. In
galvanized steel, with oil-proof handle, hardened and ground support sockets.Complete with
screw and shoe in sturdy hard rubber. Suitable for chemical and food industries, where special
hygienic conditions are required and for critical applications due to unfavorable climatic conditions
where particularly aggressive coolants are used. Min. and max. holding forces (F1-F2) expressed
in Newton (N).
Vertical type, base plane.
Size
0
1
2
3
Force min F1
N 500
800
1000 1400
Max. force F2
N 700
1100 1200 2500
Vertical dimensions as closed mm 90
105
144
206
Horizontal dimensions as closed mm 49
60
82
112
Presser dimensions
mm M 4x25 M 5x30 M 6x35 M 8x45
Weight
grams 60
105
175
335
2834GA
Each 47,40 52,10 67,20 94,20
vuoto
DIMENSIONS:(mm)
Gr. a b c d e f
g h k l
m n
α
0 4 31 13,5 4,5 16 10 8,5 17,5 4,3 -
23 - 95
°
1 5 38 16 4,5 19 14 - 20 5,5 -
24 - 95
°
2 6 51 20 5,5 25 20 24 25 6 12,5 30 27 105
°
3 8 80 20 7,1 43 27 - 35 7,5 -
32 - 105
°
CLAMPINGDEVICES INSTAINLESSSTEEL
2834GB
INOX
Product description as Art. 2834GA
Horizontal type, base plane.
Size
0
1
2
3
Force min F1
N 250
800
1000 1800
Max. force F2
N 400
1100 1200 2500
Vertical dimensions as closed mm 22
30
44
48
Horizontal dimensions as closed mm 85
130
176
221
Presser dimensions
mm M 4x25 M 5x30 M 6x35 M 8x45
Weight
grams 35
105
185
320
2834GB
Each 41,90 59,30 65,80 82,10
vuoto
DIMENSIONS:(mm)
Gr. a b c d e f
g h k l
m n
α
0 4 26 16,0 4,3 11 10 11,2 15 4,0 -
16 - 90
°
1 5 40 15,0 4,8 26 11 13,0 20 5,5 -
22 18 90
°
2 6 64 26,0 5,5 35 22 - 25 6,0 12,7 29 20 90
°
3 8 72 25,5 6,5 44 22 - 33 7,0 -
29 23 90
°
CLAMPINGDEVICES INSTAINLESSSTEEL
2834GL
INOX
Product description as Art. 2834GA
Threaded rod type, base plane.
Size
1
3
5
Max. force F2
N 1000 1500 2500
Tie rod stroke
mm 5
12
12
Vertical dimensions as closed mm 33
36
70
Horiz. dimensions as closed (i) mm 148
242
320
Weight
grams 100
270
850
2834GL
Each 85,30 91,70 151,00
vuoto
DIMENSIONS:(mm)
Gr.
b c d g h k l
m n R
3
67 - 79 19 8 5,5 23 13 40 32 - 35 46 5,5
5
58 - 70 29 12 11 49 13 55 60 88 8
1
36 - 41 19 6 4,5 22,5 6 31 28
41 4,5
