669 / 1410
669
Prices in EURO - VAT not included
669
PERMANENT MAGNETS FOR RAISING
9
PERMANENT MAGNETS FOR RAISING
2815Z
Prod. SCU
Powerful NEODIMIO magnet. Sturdy and compact lifting device with lifting hook and control lever
for magnet activation/deactivation, with safety lock. Manufactured according to European safety
standards. Suited to lift and handle cast iron, iron, steel flat and round parts, plates, bars, pipes,
etc.
Plate max load capacity
Kg
300
600
1000
2000
Plate min. thickness
mm 20
30
40
55
Round bar max load capacity Kg
100
200
330
1000
Round bar min. Ø
mm 50
70
75
100
Round bar max Ø
mm 300
400
450
600
Weight
Kg
10
20
38
95
Dimensions B
mm 92
120
156
210
Dimensions H
mm 178
220
277
333
Dimensions H1
mm 97
120
129
167
Dimensions L1
mm 160
210
312
443
Dimensions L
mm 210
260
350
490
Dimensions R
mm 175
220
280
380
Hook bore Ø dimensions
mm 45
56
57
68
2815Z
Each 514,00
856,00 1.720,00 3.420,00
To choose the right lifting capacity, see thickness, surface finish tables and air gap.
(table section)
vuoto
PERMANENTMAGNETSFORRAISING
MAGNETIC BLOCKS
2816A
Prod. SCU
Heat resistance: 450°C
In ALNICO alloy, completely magnetised.
Cylindric-type
Ø
mm
6
8
10
Height
mm 20
25
30
2816A
Each 2,34
3,54
5,32
vuoto
MAGNETICBLOCKS
2816B
Product description as Art. 2816A
Rectangular-type
Width x thickness
mm
10x5 12,5x5 15x5 15x10
Height
mm 20
40
60
75
2816B
Each 3,54
7,10 10,70 19,40
vuoto
MAGNETICBLOCKS
PERMANENT CERAMIC MAGNETS
2817A
Prod. SCU
In ceramic material with metal coating.
Cylindric-type with fixing hole.
Ø
mm
45
53
71
Thickness
mm 10
10
15
Bore Ø
mm 4
4
10
Magnetic force
Kg
7
15
30
2817A
Each 10,50 13,70 16,10
vuoto
PERMANENTCERAMICMAGNETS
2817B
Product description as Art. 2817A
Cylindric-type with external thread.
Ø
mm
22
32
Thickness
mm 6
7
Magnetic force
Kg
3
8
Ø x length threaded stem M.
5x10 5x15
2817B
Each 5,16
6,92
vuoto
PERMANENTCERAMICMAGNETS
