675 / 1410
675
Prices in EURO - VAT not included
675
CLAMPING DEVICES
9
2829RA
Nuts with washer
Thread (M)
M.
6
8
10
12
14
16
18
Height x key opening (HxS) mm 9x10 12x13 15x17 18x19 21x22 24x24 27x27
Washer (D) Ø
mm 14
18
22
25
28
31
34
Washer (A) thickness
mm 3
3,5
4
4
4,5
5
5
2829RA
Each 1,50
1,60
1,78
2,18
2,82
3,36
6,36
Thread (M)
M.
20
22
24
Height x key opening (HxS) mm 30x30 33x32 36x36
Washer (D) Ø
mm 37
40
45
Washer (A) thickness
mm 6
6
6
2829RA
Each 5,28
7,94 10,00
vuoto
CLAMPINGDEVICES
2829S
Convex washers, DIN 6319 C.
For screws
M.
6
8
10
12
14
16
20
24
Bore Ø
mm 6,4
8,4 10,5 13
15
17
21
25
Ext. Ø x length
mm 12x2,3 17x3,2 21x4 24x4,6 28x5 30x5,3 36x6,3 44x8,2
2829S
Each 0,74 0,84 1,02 1,24 1,50 1,70 1,98 2,84
vuoto
CLAMPINGDEVICES
2829T
Wide washers, DIN 6340.
For screws
M.
6
8
10
12
14
16
18
Bore Ø
mm 6,4
8,5
10,5
13
15
17
19
Ext. Ø x length
mm 17x3 23x4 28x4 35x5 40x5 45x6 45x6
2829T
Each 0,50
0,60
0,78
0,94
1,10
1,34
1,50
For screws
M.
20
22
24
Bore Ø
mm 21
23
25
Ext. Ø x length
mm 50x6 50x8 60x8
2829T
Each 1,86
2,54
3,30
vuoto
CLAMPINGDEVICES
2829TA
Turned washers
For screws
M.
6
8
10
12
14
16
18
Bore Ø
mm 6,6
8,4
10,5
13
15
17
19
Ext. Ø x length
mm 13x3,5 18x4 22x4 28x5 35x6 35x6 40x6
2829TA
Each 0,50
0,66
0,80
0,88
1,20
1,26
1,42
For screws
M.
20
22
24
Bore Ø
mm 21
23
25
Ext. Ø x length
mm 40x6 45x8 45x8
2829TA
Each 1,42
1,68
1,84
vuoto
CLAMPINGDEVICES
2829V
Concave washers, DIN 6319 D.
For screws
M.
6
8
10
12
14
16
20
24
Bore Ø
mm 7,1
9,6
12 14,2 16,5 19
23,2
28
Ext. Ø x length
mm 12x2,8 17x3,5 21x4,2 24x5 28x5,6 30x6,2 36x7,5 44x9,5
2829V
Each 0,74 0,84 1,02 1,24 1,50 1,70 1,98 2,84
vuoto
CLAMPINGDEVICES
2829Z
Concave washers, oversize DIN 6319 G.
For screws
M.
6
8
10
12
14
16
20
24
Bore Ø
mm 7,1
9,6
12 14,2 16,5 19
23,2
28
Ext. Ø x length
mm 17x4 23x4 28x5 35x5 40x5 45x6 50x8 60x10
2829Z
Each 1,18 1,26 1,42 1,52 1,68 2,02 4,36 4,86
vuoto
CLAMPINGDEVICES
2830A
Screw-adjustable supports. Enamelled.
Max height
mm
50
70
100
140
210
Min height
mm 38
54
70
100
140
Base Ø x plate (Dxd)
mm 34x34 50x50 50x50 70x65 80x70
Max load capacity
kN 20
60
60
105
180
Weight
Kg 0,19
0,62
0,90
2,60
4,60
2830A
Each 21,80 33,50 38,50 66,90 114,00
50mm size has no central hole.
vuoto
CLAMPINGDEVICES
2830B
High-type. (ATLAS model).
Max height
mm
140
200
320
550
Min height
mm 100
140
200
320
Fastening groove (A) width mm 18
18
22
22
Portata max
kN 60
60
40
25
Weight
Kg 1,75
2,20
3,40
4,85
2830B
Each 83,70 109,00 151,00 210,00
