679 / 1410
679
Prices in EURO - VAT not included
679
CLAMPING DEVICES
9
2832GL
Product description as Art. 2832GA
Thrust and traction type, base plane.
Size
0
1
2
3
5
Force min F1
N 800
1000 2000 2500 4500
Max. force F2
N 800
1000 2000 2500 4500
Vertical dimensions as closed (i)
mm 46
60
95
96
131
Horizontal dimensions as closed mm 96
121
165
190
239
Presser dimensions
mm M 4x20 M 4x20 M 6x25 M 8x35 M 12x50
Weight
grams 65
125
325
445
880
2832GL
Each 48,40 49,90 54,70 62,40 97,40
vuoto
DIMENSIONS:(mm)
Gr. Ø a b c d e f
g h
k
l
m n M
0 6,5 33 16 4,5 13 16 16 12 M 10x1 10 16 25 M 4
1 8 44,5 20 4,5 20 20 16 15 M 12x1,5 16 19 30 M 4
3 12 69 32 6,5 30 30 30 25 M 20x1,5 22 42 60 M 8
5 16 81,5 40 8,5 50 35 30 30 M 24x1,5 25 45 65 M12
2 10 57,5 25 5,5 25
-
28 20 16x1,5 M 19 36 50 M 6
CLAMPINGDEVICES
2832GP
Product description as Art. 2832GA
Threaded rod type, base plane.
Size
1
3
5
Max. force F2
N 2000 3000 5000
Tie rod stroke
mm 5
12
12
Vertical dimensions as closed mm 33
36
70
Horiz. dimensions as closed (i) mm 148
242
320
Weight
grams 100
270
850
2832GP
Each 47,40 52,80 82,80
vuoto
DIMENSIONS:(mm)
Gr.
b
c d g h k l
m n R
3
67 - 79 19 7,1 5,5 23 13 40 32-35 46 5,5
5
58 - 70 29 12 11 49 13 55 60 88 8
1
36 - 41 19 5,3 4,5 22,5 6 31 28 41 4,5
CLAMPINGDEVICES
2832GS
Product description as Art. 2832GA
Supports for Art. 2832 GP.
Size
1
3
5
Vertical dimensions as closed (i) mm 29
29
61
Horiz. dimensions as closed (l) mm 31
40
55
Weight
grams 40
70
320
2832GS
Each 17,90 21,10 26,20
vuoto
Gr.
b c d g h k
m n o
3 6 19 10 5,5 23 13 32-35 46 10,8
5 12 29 15 11 49 13
60
89 13,7
DIMENSIONS:(mm)
1 6 19 8 4,5 22,5 6
28
41 6,8
CLAMPINGDEVICES
