QUICK-CHANGE TOOL BLOCKS
QUICK-CHANGE TOOL BLOCKS
1587
Prod. SCU
In forged steel, hardened and ground. With 5 tool-holders: 3 x standard tool-holders and 1 with
ptismatic lock, 1 tip-holder, 2 wrenches included. High-precision finish.
Body dimensions
mm
70x70 80x80 100x100 115x115 126x126 145x145
Height
mm 45
55
60
75
85
95
Central bore
mm 14
14
20
25
25
32
For tools up to thickness mm 16
20
21
26
31
36
Drive
C.M.
1
1
2
3
3
4
Weight
Kg
3,5
5
9
15
19
27
1587
Each 842,00 897,00 915,00 1.070,00 1.240,00 1.470,00
vuoto
Spare flat seat tool holder. For Art. 1587.
Body dimensions
mm
70x70 80x80 100x100 115x115 126x126 145x145
O1587A
Each 112,00 112,00 112,00 129,00 160,00 193,00
vuoto
Spare V-seat tool holder. For Art. 1587.
Body dimensions
mm
70x70 80x80 100x100 115x115 126x126 145x145
O1587B
Each 119,00 119,00 119,00 143,00 174,00 207,00
vuoto
Spare tool holder with Morse cone. For Art. 1587.
Body dimensions
mm
70x70 80x80 100x100 115x115 126x126 145x145
O1587C
Each 214,00 214,00 214,00 266,00 289,00 381,00
vuoto
These parts are only suitable for turrets supplied by us.
vuoto
T-wrenches. Square socket. In forged steel. Burnished. For Art. 1587.
Opening
mm
7
9
10
12
For turrets
mm 70x70/80x80
100x100
115x115/126x126 145x145
O1587E
Each
23,80
23,80
31,10
33,90
vuoto
Offset socket wrenches. Hexagonal opening.
In forged steel. Burnished. For Art. 1587.
Opening
mm
10
12
14
17
21
For turrets
mm 70x70
80x80 100x100 115x115/126x126 145x145
O1587F
Each 35,70
35,70
35,70
43,10
60,40
vuoto
QUICK-CHANGETOOLBLOCKS
BUCKLING KNURLING TOOLS
1592GA
AA
HSS
Prod. SCU
Professional model according to DIN 403 for knurling according to DIN 82. Diameter: 20mm.
Thickness: 8mm. Hole: 6mm. In special QUICKSUPER steel (HSS), hardness HRc 62 (± 1).
Ground sides and bore. Fine milled toothing.
Straight profile (AA).
Pitch
mm
0,4
0,5
0,6
0,7
0,8
1
1,2
1592GA
Each 38,80 38,80 38,80 38,80 38,80 38,80 38,80
Pitch
mm
1,4
1,5
1,6
1,8
2
1592GA
Each 38,80 38,80 38,80 38,80 38,80
