206 TORQUE WRENCHES WITH MALE DRIVE
Prices in EURO - VAT not included
3
206
809GA
809GB
809GC
16 Orig. Gedore
Click type. Light alloy body. Inside components in alloyed steel. ± 3% tolerance of the scale set
torque. Double scale Nm/lbf on handle. Adjustment by means of the jointed socket built-in in the
handle. Audible acustic signal ("click") on reaching preset torque value. For controlled bi-
directional tightening.
Supplied with test certificate as per DIN ISO 6789.
Type with straight connection with male pin.
Art...................................... 809GA 809GB 809GC
Pivot drive Ø mm 16 16 16
Tightening capacity Nm 8-40 25-120 80-400
Tightening capacity 70-350 - -
Tightening capacity - 18-90 60-300
Scale division 5 Nm/50 5 Nm/5 5 Nm/5
Overall length mm 365 490 642
Weight Kg 1 1,45 2
Supplier code .................... 8460-01 8461-01 8462-01
Each 548,00 609,00 764,00
vuoto
TORQUEWRENCHESWITHMALEDRIVE
809GD 22 Orig. Gedore - Art. 8463-10
Product description as Art. 809GA
Pivot drive Ø mm 22
Tightening capacity Nm 140-620
Tightening capacity 105-450
Scale division 10 Nm/10
Overall length mm 845
Weight Kg 3
809GD Each 1.450,00
TORQUEWRENCHESWITHMALEDRIVE
809GE 28 Orig. Gedore - Art. 8471-01
Product description as Art. 809GA
Pivot drive Ø mm 28
Tightening capacity Nm 520-1000
Tightening capacity 380-730
Scale division 10 Nm/10
Overall length mm 845
Weight Kg 3
809GE Each 2.060,00
Art. 809 GE: supplied with bar. Wrench overall length: 1330mm.
vuoto
TORQUEWRENCHESWITHMALEDRIVE
BITS WITH 16 MM DIAMETER FEMALE COUPLING
809GF 16 Orig. Gedore
Made from CHROME-VANADIUM steel.
For all torque wrenches with male Ø 16mm connector.
Open end fitting.
Opening mm 7 8 9 10 11 12 13
809GF Each 52,20 52,20 52,30 52,20 52,20 52,20 52,20
Opening mm 14 15 16 17 18 19 20
809GF Each 52,20 52,20 52,20 52,20 52,20 52,20 52,20
Opening mm 21 22 23 24 25 26 27
809GF Each 55,70 55,70 56,10 55,70 56,10 60,70 60,70
Opening mm 28 29 30 32 36
809GF Each 60,70 60,70 60,70 60,70 60,70
Inch sizes are available on request.
BITSWITH16MMDIAMETER FEMALECOUPLING
809GH 16 Product description as Art. 809GF
Bihexagonal ring end fitting.
Opening mm 7 8 9 10 11 12 13
809GH Each 54,70 54,40 54,40 54,30 54,40 54,40 54,30
Opening mm 14 15 16 17 18 19 20
809GH Each 54,30 54,30 54,30 54,30 54,30 54,30 54,70
Opening mm 21 22 23 24 27
809GH Each 56,90 56,80 56,80 56,80 57,10
Inch sizes are available on request.
BITSWITH16MMDIAMETER FEMALECOUPLING
809GHA 16 Product description as Art. 809GF
Bihexagonal open end fitting.
Opening mm 7 8 9 10 11 12 13
809GHA Each 64,40 64,40 64,40 63,60 64,40 64,40 65,10
Opening mm 14 15 16 17 18 19 20
809GHA Each 69,90 65,50 69,10 69,30 72,30 71,70 72,30
Opening mm 21 22 24 27
809GHA Each 76,40 78,20 78,20 79,90
vuoto
BITSWITH16MMDIAMETER FEMALECOUPLING
