TORQUE WRENCHES WITH MALE DRIVE
3
Prices in EURO - VAT not included 205
TORQUE WRENCHES WITH MALE DRIVE
808GL
808GP
808GR
808GS
808GT
808GV
16
Orig. Gedore
Click type. Handy construction. Adjustment obtained by rotating the ergonomically shaped nylon
handgrip, safety lock at the extremity.± 3% tolerance of the scale set torque.
Double scale with graduation Nm on handle below a window with a magnifying-glass effect
that makes reading easier. For controlled bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
Type with straight coupling with male pin.
Art. ............................. 808GL 808GP 808GR 808GS 808GT 808GV
Pivot drive Ø mm 16 16 16 16 16 16
Tightening capacity Nm 5-25 10-50 20-100 40-200 60-300 80-400
Tightening capacity 3,5-18 7,5-37 15-75 30-150 45-220 60-300
Scale division 0,1 Nm 0,25 Nm 0,5 Nm 1 Nm 1 Nm 1 Nm
Overall length mm 279 329 377 468 559 646
Weight Kg 0,33 0,39 0,7 0,86 1,08 1,39
Supplier code ............. 4400-02 4405-05 4410-01 4420-01 4430-01 4440-01
Each 183,00 193,00 211,00 242,00 280,00 385,00
vuoto
TORQUEWRENCHESWITHMALEDRIVE
808GZ 1
new
808GZ 2
new
808GZ 3
new
22
Product description as Art. 808GL
Art...................................... 808GZ 1 808GZ 2 808GZ 3
Pivot drive Ø mm 22 22 22
Tightening capacity Nm 110-550 150-750 250-850
Tightening capacity 80-405 110-550 185-630
Scale division 1 Nm 1 Nm 1 Nm
Overall length mm 917 1198 1345
Weight Kg 3 4,06 4,43
Supplier code..................... 4450-01 4475-01 4485-01
808GZ 1 Each 658,00 768,00 1.110,00
vuoto
TORQUEWRENCHESWITHMALEDRIVE
808H 16
Orig. Gedore - Dremaster Z
Release type model.
Easy to handle. Can be adjusted by rotating the ergonomic handle with safety lock, which
includes visual monitoring located at the far end. An additional quick adjustment is also possible
by using round tenders, although these are not provided. Dual component handle with soft, non-
slip grip with a clear path through to the centre providing an accurate hold and an accurate
calibration process. Tolerance: ± 3% for each scale reading. Dual scale Nm reading which
can be selected by using the cursor, and which helps to avoid any potential reading errors.
Micrometric adjustments with Nm values.
Equipped with items certified as per DIN ISO 6789:2003.
Type II, Class A.
Type with straight coupling with male pin.
Size 100 200 300 400
Pivot drive Ø mm 16 16 16 16
Tightening capacity Nm 20-100 40-200 60-300 80-400
Tightening capacity 15-75 30-150 45-220 60-300
Scale division 0,5 Nm 1 Nm 1 Nm 1 Nm
Overall length mm 405,5 496,5 587,5 677,5
Weight Kg 0,9 1,1 1,3 2,2
Supplier code..................... DMZ 100 DMZ 200 DMZ 300 DMZ 400
808H Each 234,00 269,00 309,00 428,00
Wrenches Art. 808 H with inserts and ratchets can be supplied on request in a metal case.
vuoto
TORQUEWRENCHESWITHMALEDRIVE
808M 22
Product description as Art. 808H
Type with straight coupling with male pin.
Size 550 750 850
Pivot drive Ø mm 22 22 22
Tightening capacity Nm 110-550 150-750 250-850
Tightening capacity 80-405 110-550 185-630
Scale division 1 Nm 1 Nm 1 Nm
Overall length mm 913 1194 1341
Weight Kg 3,6 4,7 5
Supplier code..................... DMZ 550 DMZ 750 DMZ 850
808M Each 733,00 853,00 1.240,00
