Catalogo SICUTOOL 2017 - Versione inglese con prezzi

187 / 1410

187
PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE, WITH SIGNAL OUTPUT SISTEM
3
Prices in EURO - VAT not included 187
794GHB
Orig. Torqueleader - Art. D94402
CONNECTION CABLES
between the electrical switch Art. 794 GHA and the line production control system or signal unit
Art. 794 GHE.
Flat cable, total length 5 m.
794GHB Each 191,00
When stocks will be run out, will be shipped the same item marked Gedore.
vuoto
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
794GHC
Orig. Torqueleader - Art. D94406
Product description as Art. 794GHB
Coiled cable, total length in in extension approx. 5 m.
794GHC Each 295,00
When stocks will be run out, will be shipped the same item marked Gedore.
vuoto
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
794GHE
Orig. Torqueleader - Art. C12870
SERVICE DATA UNIT (SDU) that allows you to amplify, stabilize and adjust the signal transmitted
by the torque wrenches by means of a switch (Sw) Art. 794 and 804 GH 5-10-25-55-125 GA 2-10-
25-65- 135.
This system reduces the risk of failure to report the activation of the torque wrench.
The unit can be powered by 4 AA alkaline batteries (Art. 3600 E, not supplied) or DC 6V. It is
connected to the torque wrenches via cables Art. 794 GHB/C and to the external devices via
output contacts to 5 A for 110 V AC or 24 V DC.
Equipped with 1 YELLOW LED to battery power insufficient, 1 RED LED when no signal is
transmitted, 1 GREEN LED when the signal is transmitted.
794GHE Each 579,00
When stocks will be run out, will be shipped the same item marked Gedore.
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
PRECISION TORQUE WRENCHES
794GM
794GP
Orig. Torqueleader
Sliding model, with scale. High precision tightening on pre-set torque value.
Over-tightening is not possible. Serial assembling and long-term work. Automatic reset. Stainless
steel heads, body in special aluminium alloy, ergonomic non-slip rubber handgrip. Integrated
ratchet function.
Right operation.
Supplied with test certificate as per DIN ISO 6789.
± 6% tolerance of the scale set torque.
Art...................................... 794GM 794GP
Square drive inch 1/4 1/4
Tightening capacity Nm 1-5 2-10
Scale division 0,05 Nm 0,1 Nm
Overall length mm 195 195
Weight Kg 0,24 0,24
Supplier code..................... TSC 5 TSC 10
Each 432,00 443,00
vuoto
When stocks will be run out, will be shipped the same item marked Gedore.
PRECISIONTORQUEWRENCHES
794GR
794GS
794GT
Orig. Gedore
Click type.
For precise, even tightening of screws and bolts. Tolerance: ± 3% for each scale reading. High
quality performance ensured. Gedore torque wrenches are characterised by the high resistance
of their light alloy body and alloyed steel component parts. Adjusted using a jointed socket that is
extracted from the handle. Audible signal ("click") on reaching the set torque value. Square drive
for right-handed operation. Two square drives for right/left-handed operation.
Supplied with DIN ISO 6789 test certificate.
Torque wrenches Art. 794GS / 795G 2-6-10-14-22-24A-26-30-34-36E-38-41 are supplied in a
case also designed to hold relevant accessories such as sockets, extensions, ratchet heads, etc.
Art...................................... 794GR 794GS 794GT
Square drive inch 1/4 1/4 1/4
Tightening capacity Nm 6-30 6-30 6-30
Tightening capacity 50-270 50-270 50-270
Scale division 1 Nm/10 1 Nm/10 1 Nm/10
Overall length mm 265 265 265
Weight Kg 0,6 0,9 0,6
Frame Simple right D Simple right D Double right and left D-S
Package in case Plastic Plastic box Plastic
Supplier code..................... 8554-01 8554-02 8559-01
Each 472,00 539,00 491,00
PRECISIONTORQUEWRENCHES
