1238 / 1410
1238
Prices in EURO - VAT not included
1238
MACHINE TAPS
13
9269G
M
HSS-E
TIN
INOX
Orig. Völkel - Art. 356 TIN
THROUGH SHANK
RIGHT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 376) – M Coarse Metric – Tolerance ISO2X/6HX.
HSS-E-TIN. Short chamfer, chipless. For aluminium and aluminium alloys, metals up to R 900 N/
mm², stainless steel. Roll taps with coolant ejection channels. Through and blind holes.
TIN coating.
Ø
mm
12
14
16
Pitch
mm 1,75
2
2
Overall length
mm 110
110
110
Thread length
mm 29
30
32
Shank Ø
mm 9
11
12
Shank square
mm 7
9
9
9269G
Each 46,50 67,40 78,20
vuoto
MACHINETAPS
MACHINE TAP WITH COLOURED RINGS
9271GL
M
HSS-E
Orig. Völkel - Art. 353
GREEN collar.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Ground and polished after hardening.
Reinforced shank (12mm, reduced shank), with chamfer suitable for through holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For steel up to 1000 N/sqmm, cast iron, aluminium, copper brass, and other long chip materials.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9271GL
Each 12,40 12,40 13,60 13,60 15,70 21,70 27,80
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 30
32
34
34
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9271GL
Each 31,40 34,20 46,30 64,10
vuoto
MACHINETAPWITHCOLOUREDRINGS
9271GM
new
M
HSSE-PM-TIN
Orig. Völkel - Art. 300
GREEN collar.
Sintered SUPER-FAST class HSS-E steel, TIN coated, for superior performance.
Ground and polished after hardening.
Reinforced shank (from 12mm, reduced shank), correct chamfer for through holes.
Thread: Metric - Coarse Pitch M - DIN 13 (DIN 371/376).
Right-hand use.
For non- and low-alloy steel up to 1000 N / mm², stainless steel and alloys, aluminum, copper and
alloys, and long-chipping materials.
Ø
mm
3
4
5
6
8
10 12 14 16
Pitch
mm 0,5 0,7 0,8 1 1,25 1,5 1,75 2
2
Overall length
mm 56 63 70
90 100 110 110 110
Thread length
mm 11 13 16 19 22 24 29 30 32
Shank Ø
mm 3,5 4,5 6
6
8
10
9
11 12
Shank square
mm 2,7 3,4 4,9 4,9 6,2 8
7
9
9
9271GM
Each 25,70 25,70 27,10 29,90 35,60 49,90 74,10 110,00 129,00
vuoto
