1237 / 1410
1237
Prices in EURO - VAT not included
1237
MACHINE TAPS
13
9218G
M
HSS-E
Orig. Völkel - Art. 385
THROUGH SHANK
RIGHT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 376) – M Coarse Metric – Tolerance ISO2/6H.
HSS-E. Correct chamfer. For metals up to R 900 N/mm². Through holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 2,2
2,8
3,5
4,5
6
7
9
Shank square
mm -
2,1
2,7
3,4
4,9
5,5
7
9218G
Each 8,70
8,70
9,26
9,26 11,20 13,40 15,60
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Overall length
mm 110
110
125
140
140
160
Thread length
mm 30
32
34
34
34
38
Shank Ø
mm 11
12
14
16
18
18
Shank square
mm 9
9
11
12
14,5
14,5
9218G
Each 20,10 22,40 31,90 43,20 49,60 52,70
MACHINETAPS
9220G
M
HSS-E
Orig. Völkel - Art. 389
Product description as Art. 9218G
HSS-E. Short chamfer. Allzweck type with alternate threads, for metals up to R 900 N/mm², steel
and steel alloys. Through holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 2,2
2,8
3,5
4,5
6
7
9
Shank square
mm -
2,1
2,7
3,4
4,9
5,5
7
9220G
Each 11,90 11,90 12,40 12,40 15,10 18,10 20,80
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Overall length
mm 110
110
125
140
140
160
Thread length
mm 30
32
34
34
34
38
Shank Ø
mm 11
12
14
16
18
18
Shank square
mm 9
9
11
12
14,5
14,5
9220G
Each 27,10 29,90 42,80 57,90 66,50 71,10
MACHINETAPS
9232G
M
HSS-E
Orig. Völkel - Art. 386
Product description as Art. 9218G
HSS-E. Semi-short chamfer. Helicoidal type with approx.15° flute, for metals up to R 80 Kg/sqmm.
Blind holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 2,2
2,8
3,5
4,5
6
7
9
Shank square
mm 1,8
2,1
2,7
3,4
4,9
5,5
7
9232G
Each 12,10 12,10 12,40 12,40 15,10 18,10 20,80
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Overall length
mm 110
110
125
140
140
160
Thread length
mm 30
32
34
34
34
38
Shank Ø
mm 11
12
14
16
18
18
Shank square
mm 9
9
11
12
14,5
14,5
9232G
Each 27,10 29,90 43,30 58,30 66,50 71,10
MACHINETAPS
9260G
M
HSS-E
Orig. Völkel - Art. 387
Product description as Art. 9218G
HSS-E. Type with approx. 35° flute for deep threads with dia. more than 1 1/2. Short chamfer. For
metals up to R 900 N/mm².
Deep blind holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 6
7
8
10
14
16
18
Shank Ø
mm 2,2
2,8
3,5
4,5
6
7
9
Shank square
mm -
2,1
2,7
3,4
4,9
5,5
7
9260G
Each 10,60 10,60 11,20 11,20 13,30 16,10 18,60
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Overall length
mm 110
110
125
140
140
160
Thread length
mm 20
22
25
25
27
30
Shank Ø
mm 11
12
14
16
18
18
Shank square
mm 9
9
11
12
14,5
14,5
9260G
Each 24,10 27,10 38,50 51,30 59,90 64,10
vuoto
MACHINETAPS
