MACHINE TAPS
13
9174G
M
HSS-E
TIN
Orig. Völkel - Art. 315 TIN
Product description as Art. 9170G
HSS-E-TIN. Correct chamfer. For metals up to R 900 N/mm². Through holes. TIN coating.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9174G
Each 12,40 12,40 13,10 13,90 17,10 22,10
vuoto
MACHINETAPS
9180G
INOX
M
HSS-E
VAP
Orig. Völkel - Art. 315 VAP
Product description as Art. 9170G
HSS-E. Correct chamfer. For metals up to R 900 N/mm², stainless steel. Through holes.
Vaporized.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9180G
Each 8,84
8,84
9,40
9,40 11,40 14,10
vuoto
MACHINETAPS
9186G
M
HSS-E
Orig. Völkel - Art. 376
Product description as Art. 9170G
HSS-E. Semi-short chamfer. Helicoidal type with approx.15° flute, for metals up to R 900 N/mm².
Blind holes.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9186G
Each 10,70 10,70 11,40 11,40 14,10 17,10
vuoto
MACHINETAPS
9187G
M
HSS-E
Orig. Völkel - Art. 379
Product description as Art. 9170G
HSS-E. Proper chamfer. Allzweck type with alternate threads, for metals up to R 900 N/mm², steel
and steel alloys. Through holes.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9187G
Each 10,90 10,90 11,70 11,70 14,40 17,10
vuoto
MACHINETAPS
9188G
M
HSS-E
Orig. Völkel - Art. 377
Product description as Art. 9170G
HSSE-E. Type with approx. 35° flute, for deep threads with dia. more than 1 1/2. Short chamfer.
For metals up to R 900 N/mm².
Deep blind holes.
Ø
mm
1
1,1
1,2
1,4
1,6
1,7
1,8
Pitch
mm 0,25
0,25
0,25
0,3
0,35
0,35
0,35
Overall length
mm 40
40
40
40
40
40
40
Thread length
mm 4
4
4
5
6
6
6
Shank Ø
mm 2,5
2,5
2,5
2,5
2,5
2,5
2,5
Shank square
mm 2,1
2,1
2,1
2,1
2,1
2,1
2,1
9188G
Each 31,40 31,40 31,40 28,50 28,50 28,50 28,50
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 6
7
8
10
14
16
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9188G
Each 9,54
9,54 10,40 10,40 12,60 15,40
vuoto
MACHINETAPS
