1232 / 1410
1232
Prices in EURO - VAT not included
1232
MACHINE LONG TAPS
13
MACHINE LONG TAPS
9145G
M
HSS-E
Orig. Völkel - Art. 371
HSS-E taps.
Ground and polished after hardening.
RIGHT-HAND USE.
ISO METRIC THREAD according to DIN 13 (DIN 357) – M Coarse Metric – Tolerance ISO2/
6H.Single tap.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 70
90
100
110
125
140
180
Thread length
mm 22
25
28
32
40
45
50
Shank Ø
mm 2,2
2,8
3,5
4,5
6
7
9
Shank square
mm -
2,1
2,7
3,4
4,9
5,5
7
9145G
Each 18,60 18,60 20,10 20,10 22,80 29,90 42,10
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Overall length
mm 200
200
220
250
280
280
Thread length
mm 56
63
63
70
80
80
Shank Ø
mm 11
12
14
16
18
18
Shank square
mm 9
9
11
12
14,5
14,5
9145G
Each 52,70 64,10 72,70 79,80 95,50 107,00
vuoto
MACHINELONGTAPS
MACHINE SHORT TAPS
9150G
M
HSS-E
Orig. Völkel - Art. 615
HSSGE taps. Ground and polished after hardening.
RIGHT-HAND USE.
ISO METRIC THREAD according to DIN 13 (DIN 352) – M Coarse Metric – Tolerance ISO 2/6H.
Correct chamfer. For metals R 900 N/mm². Through holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25 1,5 1,75
Overall length
mm 40
45
48
50
56
70
75
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
6
7
9
Shank square
mm 2,7
3,4
4,9
4,9
4,9
5,5
7
9150G
Each 5,14 5,14 5,28 5,70 6,70 8,12 11,70
vuoto
MACHINESHORTTAPS
9151G
M
HSS-E
Orig. Völkel - Art. 619
Product description as Art. 9150G
Correct chamfer. ALLZWECK type. Alternate threads for metals up to R 900 N/mm². Through
holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25 1,5 1,75
Overall length
mm 40
45
48
50
56
70
75
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
6
7
9
Shank square
mm 2,7
3,4
4,9
4,9
4,9
5,5
7
9151G
Each 7,98 7,98 8,26 8,26 8,84 11,10 13,70
vuoto
MACHINESHORTTAPS
9154G
M
HSS-E
Orig. Völkel - Art. 617
Product description as Art. 9150G
Semi-short chamfer. Helicoidal type with approx. 35° flute. For metals up to R 900 N/mm². Blind
holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25 1,5 1,75
Overall length
mm 40
45
48
50
56
70
75
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
6
7
9
Shank square
mm 2,7
3,4
4,9
4,9
4,9
5,5
7
9154G
Each 6,42 6,42 6,84 7,12 8,12 9,68 12,60
vuoto
MACHINESHORTTAPS
