1193 / 1410
1193
Prices in EURO - VAT not included
1193
COUNTERSINKS
13
8852G
90
HSS-E
Orig. Dürr - Art. 217-11
Single flute, ground.
COBALT HSS-E.
For countersinking holes in iron and steel.
90° HEAD TAPER. Cylindrical shank.
Countersink max Ø
mm
5
10
15
20
25
30
040
40
Drive Ø
mm 5
10
10
10
10
12
12
15
For bores Ø
mm 1-5 1-10 2-15 2-20 2-25 3-30 3-40 3-40
Overall length
mm 50
60
65
73
80
82
92
92
8852G
Each 16,80 17,30 23,80 33,90 51,50 86,60 102,00 116,00
Countersink max Ø
mm
050
50
Drive Ø
mm 12
15
For bores Ø
mm 3-50 3-50
Overall length
mm 100 100
8852G
Each 164,00 173,00
vuoto
COUNTERSINKS
8854G
90
HSS-E
Orig. Dürr - Art. 217-41
Single flute, ground.
COBALT HSS-E.
For countersinking holes in iron and steel.
60° HEAD TAPER. Morse taper shank.
Countersink max Ø
mm
30
40
50
Drive
C.M.
2
3
3
For bores Ø
mm 3-30
3-40
3-50
Overall length
mm 114
150
152
8854G
Each 119,00 205,00 281,00
vuoto
COUNTERSINKS
COUNTERSINKS WITH INTERCHANGEABLE TOOL BITS
8856G
90
HARTMETALL
TIN
Orig. Dürr - Art. 217-00
2 flutes, with HARDMETAL interchangeable tool bits, TIN-coating for high-quality performance
and time saving, no need for resharpening. Particularly suitable for use with CNC. For
countersinking high-resistance steel.
90° HEAD TAPER - DIN 74 shape A fine. Cylindrical shank with clamping flat DIN 1835B.
Supplied without tool bits.
Countersink max Ø
mm
19
23
26
30
34
37
Countersink min Ø
mm 7
11
11
12
16
19
Cylindrical drive Ø
mm 16
16
16
20
20
20
Overall length
mm 100
100
100
100
100
100
To countersink
M.
10
12
14
16
18
20
8856G
Each 298,00 306,00 319,00 332,00 342,00 345,00
vuoto
Interchangeable tool bits for Art. 8856 G x 19 - 23.
O8856GA
Each 55,20
vuoto
Interchangeable tool bits for Art. 8856 G x 26.
O8856GB
Each 57,80
vuoto
Interchangeable tool bits for Art. 8856 G x 30-34-37.
O8856GC
Each 66,80
vuoto
Spare screws TORX T 8 (M 2.6x5) for Art. 8856 G x 19-23-26.
O8856GF
Each 6,42
vuoto
Spare screws TORX T 10 (M 3.5x6) for Art. 8856 G x 30-34-37.
O8856GL
Each 6,42
vuoto
COUNTERSINKSWITH INTERCHANGEABLETOOLBITS
COUNTERSINKS
8858G
60
HSS
Orig. Dürr - Art. 216-21
Multiple flutes, HSS ground.
For countersinking holes in cast iron.
Not equally spaced flutes for better finishing.
60° HEAD TAPER -DIN 334. Cylindrical shank.
Countersink max Ø
mm
6
8
10 12,5 16
20
25 31,5
Countersink min Ø
mm 1
1,5
1,8
2
3,2
5
7
9
Drive Ø
mm 6
8
8
8
10
10
12
16
Cutting edges
Nr
3
5
5
5
7
7
9
9
Overall length
mm 50
50
50
50
60
63
75
90
8858G
Each 38,60 29,30 37,10 33,90 47,80 55,50 84,80 107,00
vuoto
COUNTERSINKS
