666 / 1410
666
Prices in EURO - VAT not included
666
STOP PINS
9
STOP PINS
2812TE
Prod. SCU
Type with retractable pin, control head and tightening counternut to adjust the pin depth.
Made of hardened, ground, galvanised steel. Head made from thermoplastic resin. To unlock,
simply extract the pin normally by pulling the control head provided.
Pivot D Ø
mm
5
6
8
10
Thread D1 Ø
MF 10x1 12x1,5 16x1,5 20x1,5
Head D2 Ø
mm 21
25
33
33
Overall length L
mm 47
56
73
80
Overall length L1
mm 24
28
36
40
Head length L2
mm 18
22
30
30
Pivot length H
mm 5
6
8
10
Ch Hexagon opening
mm 17
19
24
30
2812TE
Each 11,60 12,50 15,10 23,10
On demand, also available the STAINLESS STEEL version.
vuoto
STOPPINS
2812TF
Serrated washers for screwing, made of steel, to be applied to the stop pins Art. 2812 TE so as to
lock them in the desired position.
For pivots 2812TE
mm
5
6
8
10
2812TF
Each 19,50 20,10 20,40 20,60
vuoto
STOPPINS
SMOOTH SPRING PLUNGERS
2812V
INOX
Prod. SCU
Ball spring plunger, smooth body. In stainless steel. Hardened ball. Ø D tolerance:+0.08.
Body Ø D
mm
4
5
6
8
Min force F1
N 3
4
6
6
Max. force F2
N 7
7
12
12
Ball D1 Ø
mm 3
4
5
6,5
Ext. overall Ø D2
mm 4,6
5,6
6,5
8,5
Presser L length
mm 5
6
7
9
Ball H extension
mm 0,8
1
1,5
1,8
Weight approx.
grams 0,3
0,6
1
2
2812V
Each 1,52
1,52
1,52
1,94
vuoto
SMOOTHSPRINGPLUNGERS
2812Z
INOX
Ball spring plunger, smooth body. Body in black thermplastic resin. Ball and spring in stainless
steel, hardened. Ø D tolerance:+0.1.
Body Ø D
mm
4
5
6
8
Min force F1
N 3
4
6
6
Max. force F2
N 7
7
12
12
Ball D1 Ø
mm 3
4
5
6,5
Ext. overall Ø D2
mm 4,6
5,6
6,5
8,5
Presser L length
mm 5
6
7
9
Ball H extension
mm 0,7
1
1,5
1,8
Weight approx.
grams 0,17
0,35
0,66
1,46
2812Z
Each 0,90
1,08
1,08
1,30
vuoto
SMOOTHSPRINGPLUNGERS
SCREWING FIXING PLUGS
2813
Prod. SCU
Self-drilling screw model for plasterboard. In nylon with fiberglass reinforcement. Helicoidal
threaded lugs for clockrwise screwing.
Overall length: 29mm, usable length: 25mm, max thread Ø: 12.3mm.
With TPS, zinc plated screw for chipboard, dimensions: 4.5x35mm. Average tightness under
traction: approx. 41kg.
Indivisible pck.
pcs
100
2813
Per pack 15,20
vuoto
SCREWINGFIXINGPLUGS
EXPANSION FIXING PLUGS
2813A
Prod. SCU
High quality nylon fixing plugs.
Fixing lugs assure high tightness.
Without screw.
Ø
mm
5
6
8
10
Length
mm 25
30
40
50
Indivisible pck.
pcs
200
200
100
50
2813A
Per pack 3,56
4,06
4,00
3,74
vuoto
EXPANSIONFIXINGPLUGS
