EXPANSION FIXING PLUGS
9
2814P
Product description as Art. 2814L
With blind nut and anti-rotation ring.
Ø for length
mm
8x65 8x80 10x75 10x110 12x85 12x120 14x100
Min bore depth
mm 50
50
60
60
70
70
80
Max use thickness
mm 15
30
15
50
15
50
20
Indivisible pck.
pcs
50
50
50
50
50
50
25
Max load on R 250
Kg
350
350
500
500
800
800
1000
2814P
Per pack 113,00 166,00 172,00 239,00 239,00 290,00 204,00
Ø for length
mm
14x130 16x110 16x130
Min bore depth
mm 80
90
90
Max use thickness
mm 50
20
40
Indivisible pck.
pcs
25
25
25
Max load on R 250
Kg
1000 1200 1200
2814P
Per pack 255,00 312,00 364,00
vuoto
EXPANSIONFIXINGPLUGS
PERMANENT MAGNETS
2815A
Prod. SCU
Heat resistance: 450°C
In ALNICO alloy. Magnetic shielding assures a longer lasting magnetic charge. Impact-proof and
heat-resistant outside protection.
Cylindric type with threaded non through hole.
Ø
mm
12,7
17,5
20,6
27
34
35
50
Height
mm 15,8
15,8
19
25,4
20
30
40
Thread bore Ø
M.
4
6
6
6
6
6
8
Magnetic force
Kg
1,5
2,5
4
9,5
6
19
45
2815A
Each 6,20
6,76
7,98 12,90 23,10 26,60 56,40
vuoto
PERMANENTMAGNETS
2815B
Product description as Art. 2815A
Cylindric type with threaded through hole.
Ø
mm
19
28,6
38
Height
mm 8
9,5
11,1
Thread bore Ø
M.
4
6
6
Magnetic force
Kg
2
3,5
15
2815B
Each 7,66
9,42 15,10
vuoto
PERMANENTMAGNETS
2815C
Product description as Art. 2815A
Cylindric type with threadless through hole and slot.
Ø
mm
12,7
19
25,4
31,7
Height
mm 9,5
12,7
15,9
25,4
Bore Ø
mm 4,7
5,4
4,8
7,5
Magnetic force
Kg
1
2
3
6,8
2815C
Each 5,72
8,06 14,20 25,80
vuoto
PERMANENTMAGNETS
2815E
Product description as Art. 2815A
Bridge-shaped type with 1 x through hole (Art. 2815 E 25-28.6) and 2 x through holes
(Art. 2815 E 57-82.5).
Max length
mm
25
28,6
57
82,5
Overall height
mm 25
29
41
54
Max width
mm 40
45
70
80
Magnetic force
Kg
6,5
9
30
50
Bores Ø
mm 5
5,5
7,5
9,5
2815E
Each 27,40 40,30 162,00 290,00
vuoto
PERMANENTMAGNETS
2815F
Product description as Art. 2815A
U-bolt-shaped type.
Height: 25.4mm. Thickness: 8mm.
2815F
Each 10,70
