DISE SPRINGS
9
Type
20P
20R 20S
20T
22.5A 22.5B 22.5C 23B 23D
23F
23L
23P
Dimensions (De) mm 20
20
20
20
22.5
22.5
22.5
23
23
23
23
23
(Di) x (t)
mm 10.2x1 10.2x1.1 10.2x1.25 10.2x1.5 11.2x0.6 11.2x0.8 11.2x1.25 8.2x0.8 8.2x1 10.2x1 10.2x1.25 12.2x1.25
Indivisible pck.
pcs
200
200
200
200
200
200
200
200
200
200
200
200
2811G Per pack 19,70
20,50
47,70
50,10
16,70
19,10
51,50
19,30
22,70
22,70
51,10
51,10
Type
23R 25B 25C 25D 25E
25F
28A 28B 28F
28L
28M 28P
Dimensions (De) mm 23
25
25
25
25
25
28
28
28
28
28
28
(Di) x (t)
mm 12.2x1.5 12.2x0.7 12.2x0.9 12.2x1 12.2x1.25 12.2x1.5 10.2x0.8 10.2x1 12.2x1.25 12.2x1.5 14.2x0.8 14.2x1
Indivisible pck.
pcs
200
200
200
200
200
200
200
200
200
200
200
200
2811G Per pack 56,80
19,70
20,80
24,90
55,30
57,60
23,80
25,30
57,60
61,70
23,80
25,30
Type
28R 28S 31.5D 31.5E 31.5F 31.5L 31.5M 34A 34B 34E
34F
34L
Dimensions (De) mm 28
28
31.5
31.5
31.5
31.5
31.5
34
34
34
34
34
(Di) x (t)
mm 14.2x1.25 14.2x1.5 16.3x0.8 16.3x1.25 16.3x1.5 16.3x1.75 16.3x2 12.3x1 12.3x1.25 14.3x1.5 16.3x1.5 16.3x2
Indivisible pck.
pcs
200
200
100
100
100
100
100
100
100
100
100
100
2811G Per pack 57,60
61,70
14,10
31,30
33,10
36,90
38,80
15,80
35,10
40,70
40,70
42,60
Type
35.5A 35.5B 35.5C 40A 40B 40E
40F
40L
40M 40P
40R 40S
Dimensions (De) mm 35.5
35.5
35.5
40
40
40
40
40
40
40
40
40
(Di) x (t)
mm 18.3x0.9 18.3x1.25 18.3x2 14.3x1.25 14.3x1.5 16.3x1.5 16.3x1.75 16.3x2 18.3x2 20.4x1 20.4x1.5 20.4x2
Indivisible pck.
pcs
100
100
100
100
100
100
100
100
100
100
100
100
2811G Per pack 15,80
35,10
48,30
48,30
54,10
54,10
55,80
57,70
57,70
23,20
50,20
55,80
Type
40T
40V
45B 45C 50B 50C 50D 50F
50L
50M 50P
50R
Dimensions (De) mm 40
40
45
45
50
50
50
50
50
50
50
50
(Di) x (t)
mm 20.4x2.25 20.4x2.5 22.4x1.75 22.4x2.5 18.4x1.5 18.4x2 18.4x2.5 20.4x2 20.4x2.5 22.4x2 22.4x2.5 25.4x1.25
Indivisible pck.
pcs
100
100
100
100
100
100
100
100
100
100
100
100
2811G Per pack 59,60
65,30
74,80
82,30
72,90
88,10
99,40
88,10
99,40
88,10
99,40
67,20
Type
50S
50T
50V
50Z
56A 56B 56C 60A 60B 60D 60E
60F
Dimensions (De) mm 50
50
50
50
56
56
56
60
60
60
60
60
(Di) x (t)
mm 25.4x1.5 25.4x2 25.4x2.5 25.4x3 28.5x1.5 28.5x2 28.5x3 20.5x2 20.5x2.5 25.5x2.5 25.5x3 30.5x2.5
Indivisible pck.
pcs
100
100
100
100
100
100
100
100
100
100
100
100
2811G Per pack 72,90
88,10
99,40 115,00 93,70 109,00 145,00 126,00 147,00 147,00 162,00 147,00
Type
60L
60M 60P
63A 63B 63C 63D 70B 70D 70E
70F
70L
Dimensions (De) mm 60
60
60
63
63
63
63
70
70
70
70
70
(Di) x (t)
mm 30.5x2.75 30.5x3 30.5x3.5 31x1.8 31x2.5
31x3
31x3.5 30.5x2.5 35.5x3 35.5x4 40.5x4 40.5x5
Indivisible pck.
pcs
100
100
100
100
100
100
100
1
1
1
1
1
2811G Per pack 153,00 162,00 179,00 134,00 151,00 177,00 192,00
2,04
2,28
3,22
3,22
4,06
Type
71A 71B 71C 80B
80F
80L
80M 90A 90B 90C 100A 100D
Dimensions (De) mm 71
71
71
80
80
80
80
90
90
90
100
100
(Di) x (t)
mm 36x2
36x2.5
36x4
31x3
41x3
41x4
41x5
46x2.5 46x3.5
46x5
41x4
51x3.5
Indivisible pck.
pcs
1
1
1
1
1
1
1
1
1
1
1
1
2811G Per pack 1,98
2,12
3,26
2,76
2,76
4,02
4,80
3,22
3,86
5,76
5,76
4,62
Type
100F
100L
Dimensions (De) mm 100
100
(Di) x (t)
mm 51x5
51x6
Indivisible pck.
pcs
1
1
2811G Per pack 7,04
9,16
DISESPRINGS
SPRING PLUNGERS WITH THREADS
2812A
Prod. SCU
Ball nose spring plunger with slotted drive. In hardened steel, 5.8 resistance class, burnished.
Thread D Ø
M.
4
5
6
8
10
12
16
20
Force min F1
N 6
6
7
15
20
30
45
60
Max. force F2
N 20
20
20
30
35
55
100 120
D1 tip Ø
mm 1,8
2,4
2,7
4
4,5
6
8,5
10
Presser L length
mm 9
12
14
16
19
22
24
30
Tip extension H
mm 1,5
2
2
2
2,5
3,5
4,5
6,5
Notch N width
mm 0,6
0,8
1
1,2
1,6
2
2,5
2,5
Weight approx.
grams 0,39
1
1,7
4
7
13
24 46,3
2812A
Each 1,72 1,72 1,72 1,96 2,16 3,26 4,34 7,20
vuoto
SPRINGPLUNGERSWITHTHREADS
2812B
Ball spring plunger with slotted drive. In hardened steel, 5.8 resistance class, burnished.
Hardened ball.
Thread D Ø
M.
3
4
5
6
8
10 12 16 20
Force min F1
N 1,5
4
6
9
15 20 30 65 80
Max. force F2
N 3
10 11 13 30 35 55 125 160
Ball D1 Ø
mm 1,5 2,5
3
3,5
5
6
8
10 12
Presser L length
mm 7
9
12 14 16 19 22 24 30
Ball H extension
mm 0,5 0,8 0,9
1
1,5
2
2,5 3,5 4,5
Notch N width
mm 0,4 0,6 0,8
1
1,2 1,6
2
2,5 2,5
Weight approx.
grams 0,2 0,6 0,9 1,5 3,5
7
10 24 44,3
2812B
Each 1,92 0,82 0,92 1,02 1,28 1,66 2,76 3,52 6,10
vuoto
SPRINGPLUNGERSWITHTHREADS
