Prices in EURO - VAT not included
661
ELASTIC PIN SETS
9
ELASTIC PIN SETS
2810Z
Prod. SCU
Set of elastic pins according to ISO 8752 DIN 1481, burnished finish. In spring steel C 70-55 Si 7.
517-pcs. set of elastic pins Art. 2811.
The set contains:
50 pcs. each mm 3x22 - 3x40
40 pcs. each mm 4x16 - 4x22 - 4x30 - 4x40 - 4x50
24 pcs. each mm 5x30 - 5x50 - 5x60
30 pcs. each. mm 6x16
10 pcs. each mm 6x40 - 6x50 - 6x80
20 pcs. each mm 6x60
5 pcs. each mm 7x80
12 pcs. each mm 8x40 - 8x55 - 8x60 - 8x80
6 pcs. each mm 10x40 - 10x80
2810Z
Each 278,00
vuoto
ELASTICPINSETS
ELASTIC PINS
2811
Prod. SCU
Model according to ISO 8752 DIN 1481, burnished finish.
In spring special steel C70-55 Si7.
Beveled extremities in dimensions up to Ø 8mm.
Only one beveled extremities in dimensions from Ø 10mm.
Mentioned packing units are not sold separately. Product in set see Art.2810 Z.
Ø for length
mm
1x4 1x5 1x6 1x8 1x10 1x12 1x14 1x16 1x20 1.5x6 1.5x8 1.5x10 1.5x12 1.5x14 1.5x16
Indivisible pck.
pcs
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 32,80 34,30 34,30 34,30 35,70 35,70 37,10 40,10 44,20 21,40 22,90 22,90 23,60 25,70 31,40
Ø for length
mm
1.5x20 2x4 2x5 2x6 2x8 2x10 2x12 2x14 2x16 2x18 2x20 2x22 2x24 2x26 2x30
Indivisible pck.
pcs
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 35,70 28,60 28,60 24,30 24,30 24,30 25,70 25,70 25,70 25,70 27,10 28,60 32,80 34,30 37,10
Ø for length
mm
2.5x5 2.5x6 2.5x8 2.5x10 2.5x12 2.5x14 2.5x16 2.5x18 2.5x20 2.5x26 2.5x30 3x4 3x5 3x6 3x8
Indivisible pck.
pcs
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 25,70 25,70 25,70 26,40 26,40 26,40 27,10 27,10 28,60 37,10 42,80 25,70 25,70 25,70 27,10
Ø for length
mm
3x10 3x12 3x14 3x16 3x18 3x20 3x22 3x24 3x26 3x28 3x30 3x32 3x36 3x40 3.5x10
Indivisible pck.
pcs
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 27,10 28,60 30,10 32,80 32,80 32,80 34,30 34,30 35,70 35,70 37,10 40,10 44,20 45,70 42,80
Ø for length
mm
3.5x12 3.5x16 3.5x20 3.5x26 3.5x30 3.5x36 3.5x40 4x6 4x8 4x10 4x12 4x14 4x16 4x18 4x20
Indivisible pck.
pcs
1000 1000 1000 1000 1000 1000 1000 500 500 500 500 500 500 500 500
2811
Per pack 37,10 40,10 41,40 45,70 51,40 54,20 57,10 15,70 16,40 17,20 17,20 17,90 19,30 19,30 20,10
Ø for length
mm
4x22 4x24 4x26 4x28 4x30 4x32 4x36 4x40 4x45 4x50 4.5x16 4.5x20 4.5x24 4.5x30 4.5x32
Indivisible pck.
pcs
500 500 500 500 500 500 500 500 500 500 500 500 500 500 500
2811
Per pack 20,10 20,70 22,10 22,90 23,60 24,30 26,40 29,30 31,40 39,30 30,10 32,10 35,70 39,30 40,70
Ø for length
mm
4.5x40 5x6 5x10 5x12 5x14 5x16 5x18 5x20 5x22 5x24 5x26 5x30 5x32 5x36 5x40
Indivisible pck.
pcs
500 500 500 500 500 500 500 500 500 500 500 500 500 500 500
2811
Per pack 47,10 25,70 21,40 21,40 22,10 25,10 25,10 25,70 27,80 29,30 30,70 32,10 33,60 36,40 38,50
Ø for length
mm
5x45 5x50 5x55 5x60 5x65 5x70 5x80 6x10 6x12 6x14 6x16 6x18 6x20 6x22 6x24
Indivisible pck.
pcs
500 250 250 250 250 250 250 500 500 500 500 500 500 500 500
2811
Per pack 40,10 22,50 24,60 26,80 32,80 32,80 37,50 26,40 27,10 27,80 30,10 30,10 30,70 32,10 35,70
Ø for length
mm
6x26 6x30 6x32 6x36 6x40 6x45 6x50 6x55 6x60 6x65 6x70 6x75 6x80 6x100 7x20
Indivisible pck.
pcs
500 500 500 500 250 250 250 250 250 250 250 250 250 250 500
2811
Per pack 39,30 42,80 45,70 50,70 25,70 28,60 32,10 33,90 35,70 46,40 46,40 57,10 64,20 104,00 59,20
Ø for length
mm
7x26 7x30 7x40 7x50 7x60 8x12 8x16 8x20 8x24 8x26 8x30 8x32 8x36 8x40 8x45
Indivisible pck.
pcs
500 250 250 500 250 500 500 500 500 250 250 250 250 250 250
2811
Per pack 74,90 42,80 50,10 122,00 78,50 43,50 45,70 49,20 56,40 32,10 34,60 35,70 42,80 42,80 46,40
Ø for length
mm
8x50 8x55 8x60 8x65 8x70 8x80 8x100 10x14 10x16 10x20 10x22 10x24 10x26 10x30 10x32
Indivisible pck.
pcs
250 250 250 250 250 250 100 500 500 500 500 500 500 500 500
2811
Per pack 50,10 53,50 57,10 60,60 67,80 92,70 51,40 71,30 74,90 92,70 99,90 107,00 107,00 115,00 129,00
Ø for length
mm
10x36 10x40 10x45 10x50 10x55 10x60 10x65 10x70 10x80 10x90 10x100 12x16 12x20 12x24 12x30
Indivisible pck.
pcs
250 250 250 250 250 200 200 100 100 100 100 500 500 250 250
2811
Per pack 64,20 67,80 74,90 82,10 89,20 79,90 85,60 47,10 52,80 62,80 78,50 749,00 357,00 197,00 214,00
Ø for length
mm
12x36 12x40 12x45 12x50 12x60 12x70 12x80 12x90 12x100 12x120
Indivisible pck.
pcs
200 200 100 100 100 100 50
50
50
50
2811
Per pack 172,00 172,00 85,60 92,70 99,90 99,90 53,50 85,60 129,00 164,00
FITTING TOLERANCE RANGE:
nominal Ø of pin from 1 to 3mm = tolerance (H12) mm +0.10
nominal Ø of pin from 3.5 to 6mm = tolerance (H12) mm +0.12
nominal Ø of pin from 7 to 10mm = tolerance (H12) mm +0.15
nominal Ø of pin 12mm = tolerance (H12) mm +0,18.
