461

Prices in EURO - VAT not included

6

461

KNURLING TOOLS HOLDERS

KNURLING TOOLS HOLDERS

1593GP

Prod. SCU

Industrial model, in forged steel. Burnished finish. To be installed also on numerical control lathes

(NC), high speed.

Supplied with threaded pins, without knurling tools.

1-pcs knurling tool, 30° inclined head, reversable, for axial use. Required for RAA, RBR and 30°

RBL knurling.

Suitable for component Ø from 5mm to 250mm. Length 150mm. Cross section 20x25mm.

1593GP

Each 706,00

For knurls see Art. 1593 GA to 1593 GF.

vuoto

KNURLINGTOOLSHOLDERS

1593GR

Product description as Art. 1593GP

2-pcs knurling tool, for axial use. Required for 30° RGE, 45° RGE and 60° RGE knurling.

Suitable for component Ø from 5mm to 250mm. Length 165mm. Cross section 20x25mm.

Right-hand version.

1593GR

Each 1.130,00

For knurls see Art. 1593 GA to 1593 GF.

vuoto

KNURLINGTOOLSHOLDERS

1593GT

Product description as Art. 1593GP

2-pcs knurling tool, for axial use. Required for 30° RGE, 45° RGE and 60° RGE knurling.

Suitable for component Ø from 5mm to 250mm. Length 165mm. Cross section 20x25mm.

Left-hand version.

1593GT

Each 1.130,00

For knurls see Art. 1593 GA to 1593 GF.

vuoto

KNURLINGTOOLSHOLDERS

AUTOMATIC LATHE DOGS

1595

Prod. SCU

In hardened steel.

For lathes and grinders.

Rapid workpieces turnover. Suitable for serial works.

Size

1

4

5

6

Capacity min

mm 4

24

32

40

Max capacity

mm 8

32

40

48

Weight

grams 70

320

540

780

1595

Each 55,60 77,80 88,90 134,00

Product running out of stock

vuoto

Spare spring for Art. 1595.

Size

3

4

5

6

O1595

Each 6,68

6,68

7,80

8,34

vuoto

Product running out of stock

Spare levers for Art. 1595.

Size

1

2

3

5

6

O1595A

Each 22,30 27,80 31,20 44,50 55,60

vuoto

Product running out of stock

AUTOMATIC LATHEDOGS

CLEANERS FOR CONE AND CYLINDRICAL SHANKS

1596G

Prod. SCU

For cone inside cleaning. Housing in plastic material with longitudinal inserts in synthetic leather.

Oil-proof and detergent-proof.

Type for Morse cones.

Morse cone

1

2

3

4

5

1596G

Each 19,70 21,50 23,20 36,10 47,20

vuoto

CLEANERSFORCONEANDCYLINDRICALSHANKS

1597G

Product description as Art. 1596G

Type for ISO/SK cones.

Cone ISO/SK

20

30

40

45

50

1597G

Each 24,30 22,90 30,90 49,70 60,80

vuoto

CLEANERSFORCONEANDCYLINDRICALSHANKS

1598G

Product description as Art. 1596G

Type for HSK cones.

Cone HSK

25

32

40

50

63

80

100 125

1598G

Each 75,10 71,50 75,10 77,90 82,20 94,70 104,00 158,00

vuoto

CLEANERSFORCONEANDCYLINDRICALSHANKS
