TAP HOLDER CHUCKS
1470R
1470S
1470T
Morse taper shank.
With self-balancing head. Internal and slipping parts hardened and ground.
Art. ......................................
1470R 1470S 1470T
Drive
C.M.
1
2
3
for male shank by
mm 3-10
8-14
10-20
Tapping field by
M.
3-12
10-18
14-28
Chuck height cone excluded mm 50
60
70
Each 281,00
318,00
384,00
vuoto
TAPHOLDERCHUCKS
TAPPING DEVICES
1472
Prod. SCU
With adjustable clutch. Automatic turn.
With double-clamping tap holder chuck, centring jaws and terminals for male square drive locking.
H2432
Size
1A
2
2A
3
For threads Whitworth
inch 1/8-3/8 5/16-5/8 5/16-5/8
9/16-1
For metric threading machines M.
3-10
8-16
8-16
12-24
Drive
C.M.
2
2
3
3
1472
Each 871,00
959,00
959,00 1.220,00
Spare parts available on request .
vuoto
TAPPINGDEVICES
1472E
Type with adjustable clutch. Automatic reversing.
With tap holder quick change heads for quick tap change.
To be used in combination with quick change heads Art. 1465 P - V (for Art. 1472E 1-1A)/ Art.
1465R (for Art. 1472E 2-2A-3).
Size
1A
2
2A
3
For threads Metric
M.
3-10
8-16
8-16
12-24
For threads Whitworth
inch 1/8-3/8 5/16-5/8 5/16-5/8
9/16-1
Drive
C.M.
2
2
3
3
1472E
Each 884,00
964,00
964,00 1.220,00
Spare parts available on request .
vuoto
TAPPINGDEVICES
1473
Clutch type. Without automatic turn.
With adjustable clutch, suitable for machines with reversal gear.
Size
1
2
3
For threads Whitworth
inch 1/8-3/8
5/16-5/8
1/2-7/8
For metric threading machines M.
3-10
8-16
12-22
Drive
C.M.
2
3
4
1473
Each 499,00
573,00
751,00
Spare parts available on request .
vuoto
TAPPINGDEVICES
1475
High-precision type with compression compensation (Size 10 and 16: approx. 3.5mm / Size24:
approx. 4mm) and traction (Size 10 and 16: approx. 10mm / Size 24: approx. 15mm). Suitable for
drills, tapping machines, milling machines, standard lathes and NC machines, with reversal gear.
To be used with elastic pliers type ER-DIN 6499/ISO 15488.
Size
10
16
24
For metric threading machines M.
3-10
8-16
12-24
Height L
mm 47
104
105
Height De
mm 43
49
58
Elastic pliers for Art.
1561 GF 1561 GL 1561 GN
Cylindrical drive Ø
mm 25
25
32
1475
Each 458,00
567,00
818,00
vuoto
TAPPINGDEVICES
1477
High rotation precision, suitable for pillar drills.
With adjustable clutch. Automatic turn.
To be used with ER-DIN 6499/ISO 15488 collets.
Size
10
10A
16
16A
22
22A
For metric threading machines M.
3-10
3-10
8-16
8-16
10-22
10-22
Drive
CM 2
cil. 25
CM 3
cil. 25
CM 3
cil. 32
Height L
mm 120
120
125
125
153
153
Height De
mm 67
67
75
75
90
90
Height F
mm 35
35
42
42
43
43
Elastic pliers for Art.
1561 GF 1561 GF 1561 GL 1561 GL 1561 GN 1561 GN
1477
Each 1.580,00 1.580,00 1.740,00 1.740,00 1.950,00 1.950,00
vuoto
