431 / 1410
431
Prices in EURO - VAT not included
6
431
TAPPING DEVICES
TAPPING DEVICES
1465F
Prod. SCU
Type with tap holder quick change heads for quick tap change and axial compensation. For right/left
use. Suitable for drills and lathes with reverse gear. To be used in combination with quick change
heads Art. 1465 P-V (for Art. 1465 F 1)/ 1465 R (for Art.1465 F 2)/ 1465 S (for Art. 1465 F 3).
Size
1
2
3
Drive
C.M.
2
3
4
For threads Metric
M.
3-12
8-20 14-33
L body length
mm 42
67
105
De body Ø
mm 36
53
78
D heads drive Ø
mm 19
31
48
1465F
Each 313,00 377,00 930,00
vuoto
TAPPINGDEVICES
1465G
Rapid change cartridge model with a male holder for replacing the male section without having to
amend the axels. For right and left hand use. Suitable for drills and machines which can operate in
reverse mode. Can be used in combination with rapid-change cartridges in accordance with Art.
1465 P-V.
Size
1
2
Drive
B12
B16
For threads Metric
M.
3-12
3-12
L body length
mm 56
65
De body Ø
mm 32
32
D heads drive Ø
mm 19
19
1465G
Each 178,00 195,00
vuoto
TAPPINGDEVICES
QUICK CHANGE ADAPTORS
1465P
1465R
1465S
Prod. SCU
In special steel, finely worked.
Suitable for tapping heads 1465F 1 and 1472 E 1-1A.
Dimensions (mm): De=30 D=19 L1=17 L2=4 L3=21,5 L=7.
Male drive Ø
mm
3,5
4
4,5
6
7
8
9
10
1465P
Each 42,30 42,30 42,30 42,30 42,30 42,30 42,30 42,30
vuoto
Product description as Art. 1465P
Suitable for tapping heads 1465 F 2 and 1472 E 2-2A.
Dimensions (mm): De=48 D=31 L1=30 L2=5 L3=35 L=11.
Male drive Ø
mm
7
8
9
10
11
12
14
1465R
Each 54,10 54,10 54,10 54,10 54,10 54,10 54,10
Male drive Ø
mm
16
18
1465R
Each 54,10 54,10
vuoto
Product description as Art. 1465P
Suitable for tapping heads 1465 F 3.
Dimensions (mm): De=70 D=48 L1=44 L2=6 L3=55,5 L=14.
Male drive Ø
mm
11
12
14
16
18
20
22
25
1465S
Each 175,00 175,00 175,00 175,00 175,00 175,00 175,00 175,00
vuoto
QUICKCHANGEADAPTORS
1465V
SAFETY CLUTCH model made from finely processed special steel.
Suitable for tap screws 1465 F 1 / 1465 G 1-2 e 1472 E 1-1A.
Dimensions (mm): De=32 D=19 L1=17 L2=25 L3=21,5 L=25.
Male drive Ø
mm
3,5
4
4,5
6
7
8
9
10
1465V
Each 112,00 112,00 112,00 112,00 112,00 112,00 112,00 112,00
vuoto
QUICKCHANGEADAPTORS
TAPPING AND THREADING DEVICES
1466GA
1466GB
1466GC
Prod. SCU
TAP HOLDER CHUCKS
Fixed type, suitable for lathes with reversal gear.
Precision pattern, tap clamping, self-centring. Special steel body, slipping and internal parts
hardened and ground. With tightening wrench.
Art. ............................................
1466GA 1466GB 1466GC
Int. cylindrical drive Ø
mm 12
20
25
For male drive framework by
2,1-4,9
2,7-9
3,4-14,5
Tapping field by
M.
1-6
3-16
4-24
Each 459,00
621,00
827,00
vuoto
TAPPINGANDTHREADINGDEVICES
