432 / 1410
432
Prices in EURO - VAT not included
6
432
TAPPING AND THREADING DEVICES
1466GE
1466GL
1466GP
1466GR
1466GS
DIE-HOLDER CHUCKS.
Fixed type, suitable for lathes with reversal gear.
Precision pattern, clamping of the die with screw. Special steel body.
With tightening wrench.
Art......................................
1466GE 1466GL
1466GP 1466GR 1466GS
Int. cylindrical drive Ø mm 12
20
20
25
25
For dyes Ø
mm 20x7
38x14
45x18
55x22
65x25
Each 133,00
209,00
231,00
320,00
385,00
vuoto
Reducers for Art. 1466 GE Ø 20mm to Ø 16.
O1466GT 1
Each 26,90
vuoto
Reducers for Art. 1466 GL Ø 38mm to Ø 20x7.
O1466GT 2
Each 66,10
vuoto
Reducers for Art. 1466 GL Ø 38mm to Ø 25.
O1466GT 3
Each 54,10
vuoto
Reducers for Art. 1466 GL Ø 38mm to Ø 30.
O1466GT 4
Each 54,10
vuoto
Thickness for Art. 1466 GE for tapping heads 20x5mm.
O1466GT 5
Each 8,02
Product running out of stock
vuoto
Thickness for Art. 1466 GL for tapping heads 38x10mm.
O1466GT 6
Each 18,80
Product running out of stock
vuoto
Thickness for Art. 1466 GP for tapping heads 45x14mm.
O1466GT 7
Each 22,20
Product running out of stock
vuoto
Thickness for Art. 1466 GR for tapping heads 55x16mm.
O1466GT 8
Each 25,20
Product running out of stock
vuoto
Thickness for Art. 1466 GS for tapping heads 65x18mm.
O1466GT 9
Each 34,00
Product running out of stock
vuoto
TAPPINGAND THREADINGDEVICES
1467GA
1467GB
1467GE
1467GF
1467GL
1467GP
MORSE TAPER SHANKS FOR TAP AND DIE HOLDERS
External cylindrical shank 12mm with Morse taper 1 for Art. 1466 GA - 1466 GE
1467GA
Each 135,00
vuoto
External cylindrical shank 12mm with Morse taper 2 for Art. 1466 GA - 1466 GE.
1467GB
Each 138,00
vuoto
External cylindrical shank 20mm with Morse taper 2 for Art. 1466 GB - 1466 GL - 1466 GP.
1467GE
Each 175,00
vuoto
External cylindrical shank 20mm with Morse taper 3 for Art. 1466 GB - 1466 GL - 1466 GP.
1467GF
Each 206,00
vuoto
External cylindrical shank 25mm with Morse taper 3 for Art. 1466 GC - 1466 GR - 1466 GS.
1467GL
Each 286,00
vuoto
External cylindrical shank 25mm with Morse taper 4 for Art. 1466 GC - 1466 GR - 1466 GS.
1467GP
Each 325,00
vuoto
TAPPINGAND THREADINGDEVICES
1467GR
1467GS
1467GT
CLUTCH SHANKS FOR TAP AND DIE HOLDERS
With adjustable taps and dies saving clutch. Special steel body, internal and slipping parts
hardened and ground.
Art......................................
1467GR
1467GS
1467GT
Ext. cylindrical drive Ø mm
20
20
25
Drive
C.M.
2
3
4
Threading field
M.
6-12
8-16
12-24
For tap holder / dyes holder
1466 GB / 1466 GL-P 1466 GB / 1466 GL-P 1466 GC / 1466 GR-S
Each
921,00
1.170,00
1.550,00
vuoto
TAPPINGAND THREADINGDEVICES
TAP HOLDER CHUCKS
1470L
1470M
1470P
Prod. SCU
Female conical shank.
With self-balancing head. Internal and slipping parts hardened and ground.
Art. ...........................................
1470L
1470M
1470P
For DIN drive
B16
B16
B18
for male shank by
mm
3-10
8-14
10-20
Tapping field by
M.
3-12
10-18
14-28
Chuck height drive excluded mm
50
60
70
Each
274,00
303,00
355,00
vuoto
TAPHOLDERCHUCKS
