Prices in EURO - VAT not included
6
437
90° ANGULAR ADAPTORS FOR DRILLS
90° ANGULAR ADAPTORS FOR DRILLS
1544
Prod. SCU
To be fixed to portable drill chuck for 90° angle drilling.
For RIGHT/LEFT rotation. Hexagonal shank ø 9mm. In cast aluminium. 3/8x24 male shank,
without chuck.
Chuck shank max length approx. 43mm
Drill shank max length approx. 139mm
Max rotation speed 2100 rpm.
1544
Each 79,10
For included chucks see Art. 1495 G 10P and 1500G 10E. While using the angular adaptor,
the drill must be in the rotation mode (not in the percussion mode).
vuoto
90°ANGULARADAPTORSFORDRILLS
ANGULAR THREE-JAWS CHUCKS
1545
Prod. SCU
To be fixed to portable drill chuck for 90° angle drilling.
For RIGHT/LEFT rotation. Hexagonal shank ø 9mm. In cast aluminium. With three-jaws chuck
1.5-10mm, 3/8x24 male shank and wrench.
Chuck side max length approx. 143mm
Shank side max length approx. 143mm
Max rotation speed 2100 rpm.
1545
Each 93,50
For spare chucks up to 10mm, see Art. 1495 G 10P and 1500G 10E. When using angular
chucks, the drill must be in the rotation mode (not in the percussion mode).
vuoto
ANGULARTHREE-JAWSCHUCKS
1545A
To be fixed to portable drill chuck for 90° angle drilling.
For RIGHT/LEFT rotation. Hexagonal shank ø 9mm. In cast aluminium. Complete with chuck
without wrench and rapid closing system 1.5-10mm, 3/8x24 male shank.
Chuck side max length approx. 110mm
Shank side max length approx. 147mm
Max rotation speed 2100 rpm.
1545A
Each 109,00
For spare chucks up to 10mm, see Art. 1512 GE 10 and 1513G 10. When using angular
chucks, the drill must be in the rotation mode (not in the percussion mode).
vuoto
ANGULARTHREE-JAWSCHUCKS
CHUCK ADAPTORS
1546GA
1546GB
1546GE
1546GF
Prod. SCU
For fitting chuck shanks into drills, screwdrivers, etc.
Suitable for transforming chucks with 1/2x20 female thread shank into 3/8x24 female thread.
1546GA
Each 2,44
vuoto
Product description as Art. 1546GA
Suitable for transforming chucks with 3/8x24 female thread shank into 3/8x24 male thread.
1546GB
Each 2,10
vuoto
Product description as Art. 1546GA
Suitable for transforming chucks with 1/2x20 female thread shank into 3/8x24 male thread.
1546GE
Each 3,86
vuoto
Product description as Art. 1546GA
Suitable for transforming chucks with 3/8x24 female thread shank into 1/4 E6,3 hexagonal shank.
1546GF
Each 3,64
For adaptors with SDS-plus shank see Art. 1340GR_22.
CHUCKADAPTORS
CHUCK SHANKS
1551
Prod. SCU
In steel, fully hardened and ground.
For chucks with DIN 238/1 shank hole.
Size
A
B
C
D
DA DD
E
Drive
C.M.
1
1
1
1
2
2
2
Type DIN 238/1
B10
B12
B16
B18
B10
B12
B16
Max drive
mm 10,094 12,065 15,773 17,780 10,094 12,065 15,773
1551
Each 5,04
5,34
5,34
5,96
6,04
7,90
5,86
Size
F
G GA GG GH
H
L
Drive
C.M.
2
2
3
3
3
3
3
Type DIN 238/1
B18
B22
B12
B16
B18
B22
B24
Max drive
mm 17,780 21,793 12,065 15,773 17,780 21,793 23,825
1551
Each 6,16
7,24
8,72
7,90
7,90
8,34 15,50
Size
M P
R
S
Drive
C.M.
4
4
4
4
Type DIN 238/1
B16
B18
B22
B24
Max drive
mm 15,773 17,780 21,793 23,825
1551
Each 12,10 12,10 15,50 15,50
CHUCKSHANKS
