439 / 1410
439
Prices in EURO - VAT not included
6
439
TAP HOLDER SOCKETS
COLLETS
1557GA
Prod. SCU - Orig. Fahrion
Fixed normal type.
Suitable for chucks Art. 1556 G.
In ground, hardened steel. Precision manufacture.
For drills and countersinks with Morse Taper shank, direct-attach construction.
For drills and countersinks with cylindrical shank, to be used with elastic sockets Art. 1557 GF-H-
L-M.
Type
1
1A
2A
2
2B
3A
3
3B
4A
4
5
For chuck Art. 1556G Type
1
1
2
2
2
3
3
3
4
4
4
For conical tips and countersinks up to mm 14
23
14
23
31,75
23
31,75
50
31,75
50
60
Bushes drive Art.1557 GF-H-L-M C.M.
1
2
1
2
3
2
3
4
3
4
5
Overall length
mm 78
90
87
91
108
105
109
135
131
134
173
1557GA
Each 202,00 202,00 248,00 248,00 248,00 292,00 292,00 292,00 447,00 451,00 456,00
TAPHOLDERSOCKETS
TAP HOLDER SOCKETS
1557GC
Prod. SCU - Orig. Fahrion
Clutch type.
Suitable for chuck Art. 1556 G.
Hardened and ground steel. High-precision finish.
Adjustable clutch to avoid tap breaking and ensure high-precision performances.
To be used with elastic sockets Art. 1557 GP-R-S-T.
Type
1
1A
2
2A 2B
3
3A 3B
4
4A
For chuck Art. 1556G Type
1
1
2
2
2
3
3
3
4
4
For taps with shaft Ø by
mm 2,5-8 4,5-12 2,5-8 4,5-12 9-16 4,5-12 9-16 12-22 9-16 12-22
Bushes drive Art.1557 GP-R-S-T C.M.
1
2
1
2
3
2
3
4
3
4
Overall length
mm 88
99
88
102
118
118
124
149
135
150
1557GC
Each 652,00 652,00 670,00 670,00 681,00 851,00 851,00 869,00 1.260,00 1.280,00
vuoto
TAPHOLDERSOCKETS
ELASTIC SOCKETS
1557GF
1557GH
1557GL
1557GM
Prod. SCU - Orig. Fahrion
With dragging mechanism holder. Suitable for sockets Art. 1557 GA.
FOR DRILL BITS AND COUNTERSINKS WITH DIN 6329 CYLINDRICAL SHANK
Morse taper 1. Total length 65.5mm.
Ø
mm
3
3,2
3,5
4
4,2
4,5
5
1557GF
Each 44,10 59,10 44,10 44,10 59,10 44,10 44,10
Ø
mm
5,2
5,5
6
6,2
6,5
7
7,5
1557GF
Each 59,10 44,10 44,10 59,10 44,10 44,10 44,10
Ø
mm
8
1557GF
Each 44,10
vuoto
Product description as Art. 1557GF
Morse taper 2. Total length 80mm.
Ø
mm
5
5,2
5,5
6
6,2
6,5
7
1557GH
Each 49,60 64,40 49,60 49,60 64,40 49,60 49,60
Ø
mm
7,5
8
8,5
9
9,5
10
10,5
1557GH
Each 49,60 49,60 49,60 49,60 49,60 49,60 49,60
Ø
mm
11
11,5
12
12,5
13
1557GH
Each 49,60 49,60 49,60 49,60 49,60
vuoto
Product description as Art. 1557GF
Morse taper 3. Total length 99mm.
Ø
mm
10
10,5
11
11,5
12
12,5
13
1557GL
Each 66,90 81,80 66,90 81,80 66,90 81,80 66,90
Ø
mm
14
15
16
17
18
1557GL
Each 66,90 66,90 66,90 66,90 66,90
vuoto
Product description as Art. 1557GF
Morse taper 4. Total length 124mm.
Ø
mm
14
15
16
17
18
19
20
1557GM
Each 99,10 99,10 99,10 99,10 99,10 99,10 99,10
vuoto
ELASTICSOCKETS
