430 / 1410
430
Prices in EURO - VAT not included
6
430
SELF-OPENING DIEHEADS
SELF-OPENING DIEHEADS
1460G
Prod. SCU - Sistema Rubometric
With self-opening chasers.
Manual closing. Threading adjustment.
With bore, used for long threads.
Supplied without chasers.
Size
A
B
C
D
For threads Whitworth
inch 3/32-5/16 3/16-9/16 1/4-3/4
3/8-1
For metric threading machines M.
2-8
4-14
6-18
10-24
Drive Ø
mm 16
26
40
40
1460G
Each 2.650,00 3.090,00 3.620,00 4.120,00
Product running out of stock
vuoto
SELF-OPENINGDIEHEADS
1461G
THREAD CHASERS ART. 1460 G
In SUPER RAPID HSS steel. Ground slipping surfaces.
Set of 4 chasers.
When placing the order, please specify size, diameter and lead.
Size
A A A A A A A A A A B B B B B
Threads Ø and pitch
mm
2x0.4 3x0.5 3.5x0.6 4x0.5 4x0.7 5x0.8 6x0.75 6x1 8x1 8x1.25 4x0.7 5x0.8 6x0.75 8x1 8x1.25
1461G
Per series
on request
564,00 564,00 564,00 564,00 564,00 564,00 564,00 603,00 603,00 603,00 603,00 603,00
Size
B B B B B B B C C C C C C C C
Threads Ø and pitch
mm
10x1 10x1.5 12x1 12x1.5 12x1.75 14x1.5 14x2 6x1 8x1 8x1.25 10x1 10x1.5 12x1 12x1.5 12x1.75
1461G
Per series 603,00 603,00 603,00 603,00 603,00 603,00 603,00 650,00 650,00 650,00 650,00 650,00 650,00 650,00 650,00
Size
C C C C C C C C D D D D D D D
Threads Ø and pitch
mm
14x1 14x1.5 14x2 16x1 16x1.5 16x2 18x1.5 18x2.5 10x1 12x1 12x1.5 12x1.75 14x1 14x1.5 14x2
1461G
Per series 650,00 650,00 650,00 650,00 650,00 650,00 650,00 650,00 799,00 799,00 799,00 799,00 799,00 799,00 799,00
Size
D D D D D D D D D D D D D
Threads Ø and pitch
mm
16x1 16x1.5 16x2 18x1.5 18x2.5 20x1 20x1.5 20x2.5 22x1.5 22x2.5 24x1.5 24x2 24x3
1461G
Per series 799,00 799,00 799,00 799,00 799,00 799,00 799,00 799,00 799,00 799,00 799,00 799,00 799,00
Product running out of stock
vuoto
SELF-OPENINGDIEHEADS
TAPPING AND THREADING DEVICES
1465A
Prod. SCU
In ground treated steel. Combined type for tapping and threading by using round dies.
Adjustable clutch.
For right/left use. Suitable for drills and lathes with reversal gear.
Chuck withoout device.
Size
1
2
Drive
C.M.
1
2
Dye fitting Ø
mm 38
50
Reduction bushes Ø
mm 20-25-30
30-38-45
For metric tapping by
M.
3 to 10
10 to 20
For thread by
M.
3 to 10
10 to 20
Chuck length without drive
mm 75
100
1465A
Each 334,00
434,00
Product running out of stock
vuoto
TAPPINGAND THREADINGDEVICES
1465B
Tapping device for Art. 1465 A.
Size
1
2
For metric tapping by
M.
3 to 10 10 to 20
1465B
Each 189,00 267,00
Product running out of stock
vuoto
TAPPINGAND THREADINGDEVICES
1465C
Threading device for Art. 1465 A.
Size
2
For thread by
M.
10 to 20
1465C
Each 339,00
Product running out of stock
vuoto
TAPPINGAND THREADINGDEVICES
