958 / 1410
958
Prices in EURO - VAT not included
958
DIGITAL ELECTRONIC TACHOMETERS
11
4430GD
Professional model, direct reading on display (5 digits), casing covered with rubbery material for
high protection and a more comfortable use.
Good precision equipment (±0.02% +1 digit), user friendly for measuring without mechanic
contact.
Field of measurement: 1 to 99999 revi/min.
Apply self-adhesive reflective surface on the rotating part (standard supplied).
Max. measuring distance: 0.60m.
Incorporated memory for recalling the latest, the max., the min. and the average reading.
Automatic stop after 30 sec. from the latest measurement. Indicator of discharged batteries.
Operated by 2 alkaline batteries AA. Supplied in case.
4430GD
Each 309,00
For additional reflective strips see Art. O4430 GCA.
vuoto
DIGITALELECTRONICTACHOMETERS
4430GE
Double function for contact measurement or infrared beams measurements (laser beam).
Particularly indicated for checks and measurements on moving parts, motors, operating
machines, etc.
Direct reading on display (5 digits).
High precision equipment (± 0.05% +1 digit), easy to use.
Field of measurement with contact: 5 - 19999 rev./min.
Field of measurement with infrared: 5 - 99999 rev./min.
For infrared measurements, apply the reflective strap (1 strap of 60cm included in the equipment)
on the moving part.
For contact measurements, apply the supplied accessories (2 pointers and 1 roller for surface
speeds).
Measuring distance with laser ray fro 50 to 500 mm.
Incorporated memory for recolling the last reading.
Circuit manufactured with an exclusive microprocessor LSI and quartz time base.
Operated by 4 alkaline batteries (AA)
Dimensions: 210x74x37mm.
Holding case.
4430GE
Each 335,00
Spare parts supplied on request.
vuoto
Self-adhesive reflective strips, 60cm, for Art. 4430 GE.
O4430GE
Each 15,20
vuoto
DIGITALELECTRONICTACHOMETERS
4430GF
Professional model with double function for contact measurement or light ray telemeasuring.
direct reading on display (5 digits), casing covered with rubbery material for high protection and a
more comfortable use.
Good precision equipment (±0.02% +1 digit), user friendly for measuring without mechanic
contact.
Field of contact measurement: 1 to 99999 rev/min.
Field of telemeasuring: 1 to 99999 rev/min.
Peripheral speed (with 6" wheel) from 0.10 to 1524 m/min - from 0.40 to 5000 ft/min - from 4 to
60000 in/min.
Measurement of length (with 6" wheel) from 0 to 99999 m/ft/in.
For telemeasuring apply the supplied adhesive reflective strip on the moving part.
For contact measurements apply the provided adaptor as well as the special standard tools (2
pointers and 2 wheels for peripheral speed).
Max. light ray measuring distance: 0.60m.
Incorporated memory for recalling the latest, the max., the min. and the average reading.
Field of measurement selection: m/min, m/sec., ft/min, ft/sec.,in/min, m, ft, in, rpm.
Automatic stop after 30 sec. from the latest measurement. Indicator of discharged batteries.
Operated by 2 alkaline batteries AA. Supplied in case.
4430GF
Each 432,00
For additional reflective strips see Art. O4430 GCA.
vuoto
DIGITALELECTRONICTACHOMETERS
4430GH 1
SPARE ACCESSORIES FOR ART. 4430 GF
Extension.
4430GH 1
Each 17,20
vuoto
DIGITALELECTRONICTACHOMETERS
4430GH 2
SPARE ACCESSORIES FOR ART. 4430 GF
6" wheel for peripheral speed.
4430GH 2
Each 44,50
vuoto
DIGITALELECTRONICTACHOMETERS
