962 / 1410
962
Prices in EURO - VAT not included
962
METER COUNTERS
11
4445GA
4445GB
Prod. SCU
Adds in one direction. Subtracts in the opposite direction. 5 rev. = 1 metre.
For wheels circumference 200mm.
Max speed 500 metre per min.
Zero-setting by means of movable lever.
Counts up to 9999.9 metres. Shaft diameter 6mm.
Body in aluminium zama, sturdy construction.
Digit number 5. Digit height 6mm. Dimensions 93x47x32mm.
Without wheel.
Art......................................
4445GA 4445GB
Rotation
right
left
Each 126,00 126,00
vuoto
For wheels see Art. 4452 GL - GM.
METERCOUNTERS
4445GD
4445GS
4446GD
4446GS
Prod. SCU - Orig. IVO
Adds in one direction. 2 rev. = 1 metre.
For wheels circumfurence 500mm. Max speed apporx. 100 metre per min.
Zerosetting by means of removable key.
Counts up to 999,999.9 metres.
Shaft diameter 7mm.
Digits height 7mm. Base dimensions 120x64mm.
Without hinge and without wheels.
Art......................................
4445GD 4445GS
Rotation
right
left
Each 192,00
205,00
vuoto
Product description as Art. 4445GD
With hinge, without wheel.
Art......................................
4446GD 4446GS
Rotation
right
left
Each 200,00
200,00
For wheels see Art. 4453 A-B-C.
vuoto
METERCOUNTERS
4448GD
4448GS
Adds in one direction. Subtracts in the opposite direction. 2 rev. = 1 metre.
For wheels circumference 500mm.
Max speed 200 metre per min.
Instantaneous zero-setting by means of lever movable on both sides.
Counts up to 9,999.9 metres.
Shaft diameter 7mm.
Digit height 7mm. Base dimensions 120x64mm.
Without wheel.
Art......................................
4448GD 4448GS
Rotation
right
left
Each 246,00
246,00
For wheels see Art. 4453 A-B-C.
vuoto
METERCOUNTERS
4449GD
4449GS
Prod. SCU
Adds in one direction. Subtracts in the opposite direction. 2 rev. = 1 metre.
For wheels circumference 500mm.
Max speed 500 metre per min.
Quick zero-setting by means of lever movable on both sides.
Counts up to 9,999.9 metres.
Shaft diameter 8mm.
Body in die-cast aluminium, sturdy construction.
Digit number 6. Digit height 7mm. Dimensions 130x67x53mm.
Without wheel.
Art......................................
4449GD 4449GS
Rotation
right
left
Each 198,00 198,00
vuoto
For wheels see Art. 4453 L - M.
METERCOUNTERS
