963 / 1410
963
Prices in EURO - VAT not included
963
METER COUNTERS
11
METER COUNTERS
4450GD
4450GS
Prod. SCU - Orig. IVO
Electric SUBTRACTING system.
For wheel circumference 500mm.
To preset the desired value, use the 5 buttons.
The meter counter subtracts from the preset value until it reaches zero, when it disengages an
electric contact. Automatic disengagement at zero.
See Art. 4437 G for the procedure of value presetting.
Zerosetting lever movable on both sides. To repeat the same value, just push the lever.
2 rev. = 1 metre. Counts up to 9,999.9m. Max metre per min. 250.
For wheel circumference 500mm..
For alternate current up to V 220.
Without wheel.
Art......................................
4450GD 4450GS
Rotation
right
left
Ciphers height
mm 7
7
No. of ciphers
5
5
Base dimensions
mm 142x88
142x88
Each 871,00
932,00
For wheels see Art. 4453 A-B-C.
vuoto
METERCOUNTERS
4451GD
4451GS
Prod. SCU
Electrical ADDITIONING system.
For wheel circumference 500mm. Max speed 500 m/min.
Quick zero-setting by means of lever. Body in die-cast aluminium, sturdy construction. Upon
reach of the preset value, a micro commuter is activated according to basic operation settings.
Counts up to 9,999.9 metres. Shaft diameter 8m. 2 rev. = 1m.
Digit number 5. Digit height 8mm. Dimensions 130x87x57mm.
Contact range 1 A 24 V d.c.
Without wheel.
Art......................................
4451GD 4451GS
Rotation
right
left
Each 416,00
416,00
vuoto
For wheels see Art. 4453 L - M.
METERCOUNTERS
WHEELS FOR METER COUNTERS
4452GA
4452GB
4452GC
4452GE
Prod. SCU
In duraluminium (Art. 4452 GA-B), in synthetic material (Art. 4452 GC-E). Fastening screw.
Circumference 200mm, diameter 64mm, band width 12mm (Art. 4452 GE mm 17), coupling hole
with diameter 4mm. To be mounted on meter counters Art. 4444 GD-S.
With cross-grained surface.
4452GA
Each 69,20
vuoto
Product description as Art. 4452GA
Engrailed rubber surface.
4452GB
Each 81,80
vuoto
Product description as Art. 4452GA
Smooth plastic surface.
4452GC
Each 66,00
vuoto
Product description as Art. 4452GA
Pitted rubber surface.
4452GE
Each 25,10
vuoto
WHEELSFORMETERCOUNTERS
4452GL
4452GM
In duraluminium (Art. 4452 GL), in synthetic material (Art. 4452 GM). Fastening screw.
Circumference 200mm, diameter 64mm, band width 12mm (Art. 4452 GE mm 17), coupling hole
diameter 6mm. To be mounted on meter counters Art. 4445 GA-B.
Knurled surface.
4452GL
Each 32,30
vuoto
Product description as Art. 4452GL
Pitted rubber surface.
4452GM
Each 25,10
vuoto
WHEELSFORMETERCOUNTERS
