964 / 1410
964
Prices in EURO - VAT not included
964
WHEELS FOR METER COUNTERS
11
4453A
4453B
4453C
In duraluminium. Fastening screw.
To be mounted on meter counters Art. 4445 G - 4446 G - 4448 G - 4450 G for right hand rotation
(D) and left hand rotation (S).
Art......................................
4453A
4453B
4453C
Circumference
mm
500
500
500
Wheel Ø
mm
160
160
160
Circular clamp width
mm
28
25
25
Bore Ø
mm
7
7
7
Surface
knurled
rubber knurled
rubber knurled
Each
53,70
58,40
58,40
vuoto
Spare rubber band for Art. 4453 B.
O4453E
Each
13,90
vuoto
Spare rubber band for Art. 4453 C.
O4453F
Each
13,90
vuoto
WHEELSFORMETERCOUNTERS
4453L
4453M
In duraluminium. Fastening screw. Circumference 500mm, diameter 160mm, band width 23mm,
coupling hole diameter 8mm. To be mounted on meter counters Art. 4449 GD-S and 4451 GD-S.
Knurled metal surface.
4453L
Each 53,80
vuoto
Product description as Art. 4453L
Knurled rubber surface.
4453M
Each 57,40
vuoto
Spare rubber band for Art. 4453 M.
O4453P
Each 18,90
vuoto
WHEELSFORMETERCOUNTERS
METER-COUNTERS FOR CABLES
4453R
Prod. SCU
Suitable for measuring any cable or rope having diameter from 2.5 to 10mm.
Quick reset by upper key.
Body in die-cast aluminium. Count to 999.9 m.
Right shaft side, right rotation. 1 rev. = 200mm. Dimensions 130x90x90mm.
Supplied with wheel, circumference 200mm and square, made of sheet.
4453R
Each 122,00
vuoto
METER-COUNTERSFORCABLES
IMPULSE COUNTERS
4454GA
4454GB
4454GE
Prod. SCU - Orig. IVO
To be enclosed, with spring fastening.
Electric ADDING system. Works as revolution and stroke counter.
Can be connected at any distance from the impulse-sender mounted on the operating machine.
Max speed 10 impulses per sec. The impulse must not last less than 25 milliseconds. 1 impulse
adds 1 number. Counter with 6 digits to add up to 999,999.
Digits height 4.5mm. Push button for inmediate zerosetting.
For alternate current 24 V.
4454GA
Each 183,00
vuoto
Product description as Art. 4454GA
For alternate current 110 V.
4454GB
Each 183,00
vuoto
Product description as Art. 4454GA
For alternate current 230 V.
4454GE
Each 142,00
vuoto
IMPULSECOUNTERS
4455G
4456G
4457G
To be enclosed, with screw fastening.
Electric ADDING system. Works as revolution and stroke counter.
Can be connected at any distance from the impulse-sender mounted on the operating machine.
Max speed 10 impulses per sec. The impulse must not last less than 25 milliseconds. 1 impulse
adds 1 number. Counter with 6 digits to add up to 999,999.
Digits height 4.5mm. Push button for inmediate zerosetting.
For alternate current 24 V.
4455G
Each 154,00
vuoto
Product description as Art. 4455G
For alternate current 110 V.
4456G
Each 142,00
vuoto
Product description as Art. 4455G
For alternate current 230 V.
4457G
Each 142,00
vuoto
IMPULSECOUNTERS
