953 / 1410
953
Prices in EURO - VAT not included
953
INDICATOR STANDS
11
4421GB
Professional/industrial model with magnetic base and switch on/off, prism-shaped base. High
precision, fine finish, very stable and sturdy, with central tensioning system.
Chromed arms with precision articulations, guided travel and micrometric adjustment.
Holder opening for dial indicators Ø 8mm and indicator/pointers with dovetail clamp.
Without dial indicator.
Action range
mm
200
280
420
620
Overall height
mm 310
390
570
630
Prismatic base dimensions mm 60x50x55h 60x50x55h 75x50x55h 120x60x52h
Magnet force
N
750
750
1000
1500
4421GB
Each 416,00
480,00
853,00
1.350,00
Dimensions 620mm with flat base, instead of prism-shaped base.
vuoto
INDICATORSTANDS
4421L
Orig. MIB - Art. 06071015
Magnetic rod, fully swivelling in any position.
Big magnetic force with switch on/off.
Base dimensions: length 65mm, width 50mm, height 55mm.
Total height 370mm.
Holder opening for dial indicators Ø 8mm.
Without dial indicator.
Magnet force
N 600
4421L
Each 65,80
vuoto
INDICATORSTANDS
PRECISION DIAL BENCH GAUGES
4421R
Prod. SCU
With fixed round base, for verification in hardened steel, ground and lapped.
Shiftable horizontal arm, vertical column in hardened ground steel.
Base diameter 75mm. Working height 180mm. Total height 260mm.
Column diameter 25mm. Holder opening for dial indicators Ø 8mm.
Without dial indicator.
4421R
Each 257,00
vuoto
PRECISIONDIALBENCHGAUGES
4421S
With fixed square base, for verification in hardened steel, ground and lapped.
Shiftable horizontal arm, vertical column in hardened ground steel.
Base dimensions 100x100mm. Working height 160mm. Total height 285mm.
Column diameter 26mm. Holder opening for dial indicators Ø 8mm.
Without dial indicator.
4421S
Each 283,00
vuoto
PRECISIONDIALBENCHGAUGES
DIAL BORE GAUGES
4423E
Prod. SCU
Interchangeable rods in chromed steel, ground.
Hardened contact points.
Holding case. For dial indicators with reading graduations 1/10 and 1/100 of mm.
Without dial indicator.
For int Ø by
mm 15-35
For depths up to
mm 130
4423E
Each 314,00
It is advisable to use the dial indicators Art. 4400G - 4404 GB.
vuoto
DIALBOREGAUGES
