THIMBLES, ROPE CLIPS AND SCREW PIN SHACKLES
8
2158A
INOX
Stainless steel type AISI 316.
Stainless steel thimbles.
For ropes Ø
mm
3
4
5
6
8
10
12
2158A
Each 0,42
0,48
0,54
0,80
1,34
2,32
3,00
For ropes Ø
mm
14
16
20
2158A
Each 5,36
7,82 11,90
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2158B
INOX
Product description as Art. 2158A
Stainless steel rope clips.
For ropes Ø
mm
3
5
6
8
10
12
14
2158B
Each 1,14
1,42
1,58
2,40
3,70
5,98
6,76
For ropes Ø
mm
16
20
22
26
2158B
Each 9,18 13,10 17,60 21,10
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2158E
INOX
AISI 316 stainless steel type. Not to be used for lifting.
Stainless steel screw pin shackles.
Pivot Ø
mm
4
5
6
8
10
12
14
Working load
Ton 0,03
0,06
0,10
0,20
0,30
0,50
0,60
2158E
Each 1,52
1,58
2,08
3,70
6,34 11,10 16,30
Pivot Ø
mm
16
20
Working load
Ton 0,80
1
2158E
Each 23,50 38,70
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2158F
INOX
AISI 316 stainless steel model.
Conforms with 89/392 CEE Machinery Directive.
Stainless steel screw pin shackles.
Pivot Ø
mm
8
10
12
14
16
20
Working load
Ton 0,25
0,40
0,63
0,80
1
1,60
2158F
Each 4,08
6,90 12,10 17,90 25,90 42,70
For the dimensions of redances - shackles - clips see technical tables at the end of the catalogue.
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
MALE AND FEMALE EYEBOLTS
2159T
Prod. SCU
Forged steel type. With round eye, in compliance with DIN 580.
Male eyebolts, black finish.
Metric pitch thread
M.
6
8
10
12
14
16
18
Vertical workload
Kg
75
140
230
340
500
700
930
Oblique workload
Kg
50
100
170
240
320
500
590
2159T
Each 0,80
0,82
1,22
1,72
2,56
2,62
3,88
Metric pitch thread
M.
20
22
24
27
30
36
42
Vertical workload
Kg 1200 1450 1800 2700 3200 4600 6300
Oblique workload
Kg 860
1000 1290 1750 2300 3300 4500
2159T
Each 3,94
7,96
8,10 16,40 16,90 30,30 47,20
vuoto
MALEANDFEMALEEYEBOLTS
2160
Product description as Art. 2159T
Male eyebolts, galvanized.
Metric pitch thread
M.
6
8
10
12
14
16
18
20
Vertical workload
Kg 75
140 230 340 500 700 930 1200
Oblique workload
Kg 50
100 170 240 320 500 590 860
2160
Each 0,84 0,84 1,28 1,80 2,66 2,74 4,06 4,12
Metric pitch thread
M.
22
24
27
30
36
42 48x3 48x5
Vertical workload
Kg 1450 1800 2700 3200 4600 6300 8600 8600
Oblique workload
Kg 1000 1290 1750 2300 3300 4500 6100 6100
2160
Each 8,24 8,44 17,20 17,80 31,10 48,60 74,60 74,60
The measurement MF 48x3 is fine pitch.
vuoto
MALEANDFEMALEEYEBOLTS
