612 / 1410
612
Prices in EURO - VAT not included
612
CABLE CLAMPS
8
CABLE CLAMPS
2134E
2134G
2134GA
2134GB
2134GC
Prod. SCU
Self-clamping type.
For steel cables, copper cables and steel ropes.
In forged steel, long hardened anti-sliding cheeks.
Art......................................
2134E 2134G 2134GA 2134GB 2134GC
For cable Ø
mm 1-4
3-8
5-10
8-16 12-26
Max Workload
Kg 500
1000 1700 3000 3500
Breakage load
Kg 1000 1700 3000 5500 6000
Weight
Kg 0,25
0,8
1,1
1,8
3,5
Each 73,80 104,00 120,00 169,00 356,00
vuoto
CABLECLAMPS
2134GD
2134GE
2134GF
Self-clamping type.
For ALUMINIUM cables and ropes.
In forged steel, long hardened anti-sliding cheeks.
Art......................................
2134GD 2134GE 2134GF
For cable Ø
mm 5,4-8,5 8,6-12 12,1-16
Max Workload
Kg 1000 1700 3000
Breakage load
Kg 1700 3000 5500
Weight
Kg
0,8
1,1
1,8
Each 108,00 125,00 173,00
vuoto
CABLECLAMPS
2134GH
2134GL
2134GP
2134GR
Frog-shaped type.
For steel cables. With hardened knurled cheeks.
Art......................................
2134GH 2134GL 2134GP 2134GR
For cable Ø
mm 1-4
1-5
1-8
1-12
Each 29,60 34,40 38,40 56,40
vuoto
CABLECLAMPS
MANUAL TWISTERS
2140G
Orig. Schröder - Art. 9.002.0
With hook in hardened steel and wooden handle to twist and make the eyelet at the ends of metal
wires. Apt for binding round concrete bars and for other works in the building sector, the
agricultural sector, etc.
Overall length
mm 200
2140G
Each 9,20
vuoto
MANUALTWISTERS
AUTOMATIC TWISTERS
2142G
Orig. Schröder - Art. 9.001.4
With hook in hardened steel, plastic-coated handle, with spiral pin and inside spring that
automatically rotate the hook. Apt for twisting metal wires and making eyelets at their ends.
Overall length
mm 310
2142G
Each 29,50
vuoto
AUTOMATICTWISTERS
TURNBUCKLES
2150
Prod. SCU
Galvanised steel type. In compliance with the Machinery Directive 89/392EEC.
With 2 eyelets.
Screw Ø
M.
5
6
8
10
12
14
16
Working load
Ton 0,10
0,15
0,30
0,47
0,65
0,80
1,25
2150
Each 1,32
1,90
2,64
3,80
5,56
7,56 11,50
Screw Ø
M.
18
20
22
24
Working load
Ton 1,5
1,8
2,25
2,8
2150
Each 19,20 19,50 26,20 36,60
Size M 5 not marked "CE" for small dimension.
vuoto
TURNBUCKLES
2151
Product description as Art. 2150
With 1 eyelet and 1 hook.
Screw Ø
M.
5
6
8
10
12
14
16
Working load
Ton 0,025 0,045 0,075 0,115 0,15
0,21
0,34
2151
Each 1,32
1,90
2,64
3,80
5,56
7,56 11,50
Screw Ø
M.
18
20
22
24
Working load
Ton 0,45
0,65
0,9
1,2
2151
Each 19,20 19,50 26,20 36,60
Size M 5 not marked "CE" for small dimension.
vuoto
TURNBUCKLES
