613 / 1410
613
Prices in EURO - VAT not included
613
TURNBUCKLES
8
2151E
Product description as Art. 2150
With 2 hooks.
Screw Ø
M.
5
6
8
10
12
14
16
Working load
Ton 0,025 0,045 0,075 0,115 0,15
0,21
0,34
2151E
Each 1,32
1,90
2,64
3,80
5,56
7,56 11,50
Screw Ø
M.
18
20
22
24
Working load
Ton 0,45
0,65
0,9
1,2
2151E
Each 19,20 19,50 26,20 36,60
Size M 5 not marked "CE" for small dimension.
vuoto
TURNBUCKLES
2151T
Product description as Art. 2150
With 2 forks.
Screw Ø
M.
10
12
14
16
20
22
24
Working load
Ton 0,45
0,65
0,75
1
1,40
1,80
2
2151T
Each 9,08 12,60 25,90 28,90 46,50 62,10 67,30
vuoto
TURNBUCKLES
2152
INOX
Stainless steel type AISI 316.
With 2 eyelets.
Screw Ø
M.
5
6
8
10
12
Working load
Ton 0,035 0,07 0,135 0,175 0,275
2152
Each 4,80
6,48 10,70 18,60 32,70
vuoto
TURNBUCKLES
2153
INOX
Product description as Art. 2152
With 1 eyelet and 1 hook.
Screw Ø
M.
5
6
8
10
12
Working load
Ton 0,02 0,035 0,05 0,085 0,11
2153
Each 4,80
6,48 10,70 18,60 32,70
For the dimensions of turnbuckles see technical tables at the end of the catalogue.
vuoto
TURNBUCKLES
THIMBLES, ROPE CLIPS AND SCREW PIN SHACKLES
2155
Prod. SCU
Galvanised steel type.
Zinc-coated thimbles.
For ropes Ø
mm
3
4
5
6
8
10
12
2155
Each 0,12
0,14
0,16
0,20
0,28
0,34
0,46
For ropes Ø
mm
14
16
20
22
25
2155
Each 0,54
0,74
1,68
1,80
2,48
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2156
Fully forged and galvanised steel type. In compliance with the Machinery Directive 89/392EEC.
Zinc-coated rope clips.
For ropes Ø
mm
3
5
6
8
10
11
12
2156
Each 0,34
0,42
0,54
0,60
0,88
0,92
1,38
For ropes Ø
mm
14
16
20
22
24
2156
Each 1,58
1,90
2,90
3,16
3,72
Size mm 3 not marked "CE" for small dimension.
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2157
Product description as Art. 2156
Zinc-coated screw pin shackles, with marked displacement.
Pivot Ø
mm
5
6
8
10
11
12
14
Working load
Ton 0,10
0,16
0,25
0,40
0,50
0,63
0,8
2157
Each 0,46
0,68
1,12
1,32
1,58
1,90
2,56
Pivot Ø
mm
16
20
22
25
Working load
Ton
1
1,6
2
2,5
2157
Each 3,82
6,62
8,94 12,30
Sizes mm 5 not marked "CE" for small dimension.
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2157E
new
Fully made of forged steel G9 high resistance.
"OMEGA" Zinc-coated screw pin shackles, varnished and carrying capacity marking.
Pivot Ø
inch
1/4
5/16
3/8
7/16
1/2
5/8
3/4
Working load
Ton 0,50
0,75
1
1,5
2
3,25
4,75
2157E
Each 1,42
1,56
2,22
2,96
3,90
6,28 10,20
Pivot Ø
inch
7/8
1
1.1/8 1.1/4 1.3/8 1.1/2
Working load
Ton 6,5
8,5
9,5
12
13,5
17
2157E
Each 15,70 22,70 31,60 40,40 56,20 73,10
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
