610 / 1410
610
Prices in EURO - VAT not included
610
MANUAL CHAIN HOISTS
8
2133L
Chain type. Manufactured in compliance with EUROPEAN standards.
Gears in hardened solid steel. Gearing over roller bearings. Reduction unit in grease-bath sump.
Upper and lower swivel hooks in hardened steel, with safety latch. Load and operating chains in
special steel. Tested to 50% over the maximum load limit.
Supplied with 3m long load chain and 3m long operating chain.
Load capacity
Kg
500
1000 2000 3000
Chain paths
Nr
1
1
1
2
Strain on operating chain
Kg
22
30
45
34
Minimum distance between hooks mm 255
306
386
486
Weight with chains
Kg
8
10
18
24
2133L
Each 127,00 136,00 185,00 422,00
Misura 3000 in esaurimento.
vuoto
MANUALCHAINHOISTS
BEAM CLAMPS
2133M
Prod. SCU
Manufactured in compliance with EUROPEAN standards.
Suitable for fixing lever hoists (Art. 2133 H) and chain hoists (Art. 2133 L) on double-T beams.
In special steel, with threaded screw and bolster for fast and safe adjustment.
Load capacity
Kg
1000
2000
3000
Min/max beam width
mm 75 to 220 75 to 220 80 to 320
Pliers min/max width
mm 180 to 360 180 to 360 235 to 490
Beam thickness
mm 26
26
35
Pliers lateral thickness
mm 64
74
103
Hoist drive Ø
mm 22
22
24
Weight
Kg
4,5
5
10,5
2133M
Each 71,20
79,50
143,00
Product running out of stock
vuoto
BEAMCLAMPS
TROLLEYS FOR MANUAL COAIN HOISTES
2133P
Prod. SCU
Manufactured in compliance with EUROPEAN standards.
Pushing movement, apt for manual chain hoists (art. 2133 L), sliding on lower flange f double T-
beams, conical and flat. With fall-protection and anti-tilting devices. Possibility to change the
distance between wheels. In special steel, with wheels on ball bearings.
Load capacity
Kg
500
1000
2000
Min/max beam width
mm 50 to 150 65 to 200 90 to 200
Weight
Kg
5
8,7
13,9
2133P
Each 126,00
187,00
279,00
vuoto
TROLLEYSFORMANUALCOAINHOISTES
WINCHES
2133PE
new
Prod. SCU
Hauling and lifting type. Manufactured in compliance with EUROPEAN standards. Sump in
aluminium alloy, high resistance. Automatic brake, operation control lever provided with overload
device. Grip cheeks in steel, metal rope and hook with safety latch.
HOIST WITH ROPE TO 20 MT. AND HOOK
Lifting load capacity
Kg
800
1600
3200
Traction load capacity
Kg
1200
2500
5000
Weight
Kg
6
12
22
Dimensions
mm 426x170
545x190
660x220
2133PE
Each 461,00
645,00
1.100,00
vuoto
WINCHES
2133R
Product description as Art. 2133PE
Winch without rope and hook.
Lifting load capacity
Kg
1600
3200
Traction load capacity
Kg
2500
5000
Weight
Kg
11
22
Dimensions
mm 545x280x97 660x325x116
2133R
Each 372,00
644,00
Product running out of stock
vuoto
WINCHES
