618 / 1410
618
Prices in EURO - VAT not included
618
HYDRAULIC VEHICLE JACKS
8
2220GS
Orig. Weber - Art. A50-250 - Art. A100-300
Manufactured in compliance with DIN 76024 standards and with the approval of the German
institute TÜV.
Big load capacity pistons. Large reinforced base. Double lifting pump.
The pump on the left side of the seal valve is used to bring quickly the piston to the lifting point
with a maximum load capacity of:
12.5t for the model with max load 50.000 kg
25t for the model with max load 100.000 kg.
The smaller pump, on the right side of the valve, is used to reach more slowly 50.000 kg and
100.000 kg.
Provided with overload safety valve. Indeformable, high-seal gaskets.
With lever.
Max load capacity
Kg
50000
100000
Max height as closed
mm 250
300
Max height as high
mm 405
450
Weight without lever
Kg
33
87
Oil content
l
1,4
2,8
Flow rate I left hand pump
t.
12,5
25
Flow rate II right hand pump t.
50
100
Reinforced base
mm 290x235 330x295
2220GS
Each 1.110,00 4.120,00
vuoto
Sets of spare gaskets for Art. 2220 GS.
Max load capacity
Kg
50000
100000
O2220GS
Each 118,00
222,00
THE HYDRAULIC JACKS ARE ONLY LIFTING TOOLS AND THEY HAVE TO BE USED IN COMBINATION WITH SUPPORT BRACKETS.
Size
100000
is running out of stock
vuoto
HYDRAULICVEHICLE JACKS
2221GA
Orig. Weber - Art. ATD 10-120
Manufactured in compliance with DIN 76024 standards and with the approval of the German
institute TÜV.
With flat body. Highly indicated for works in which there is small place for the hydraulic jack.
Overload safety valve.
With double telescopic piston. Cylinder seal granted by special indeformable gaskets.
With lever.
Max load capacity
Kg 10000
Max height as closed
mm 120
Max height as high
mm 230
Weight without lever
Kg
6,9
Base type
tilting
Lever movement
vertical
2221GA
Each 426,00
vuoto
Sets of spare gaskets for Art. 2221 GA.
O2221GA
Each 56,40
THE HYDRAULIC JACKS ARE ONLY LIFTING TOOLS AND THEY HAVE TO BE USED IN COMBINATION WITH SUPPORT BRACKETS.
vuoto
HYDRAULICVEHICLE JACKS
2222G
Orig. Weber - Art. ATN 10-175
Manufactured in compliance with DIN 76024 standards and with the approval of the German
institute TÜV.
With flat body. Highly indicated for works in which there is small place for the hydraulic jack.
Overload safety valve.
With double telescopic piston. Cylinder seal granted by special indeformable gaskets.
With lever.
Max load capacity
Kg 10000
Max height as closed
mm 175
Max height as high
mm 385
Weight without lever
Kg
7,9
Base type
flat
Lever movement
horizontal
2222G
Each 446,00
vuoto
Sets of spare gaskets for Art. 2222 G.
O2222G
Each 56,40
THE HYDRAULIC JACKS ARE ONLY LIFTING TOOLS AND THEY HAVE TO BE USED IN COMBINATION WITH SUPPORT BRACKETS.
vuoto
HYDRAULICVEHICLE JACKS
