DIN 2080 CONNECTION FOR CHUCKS DRILLS HOLDER
DIN 2080 CONNECTION FOR CHUCKS DRILLS HOLDER
1560GAM
Prod. SCU
For chucks with "B" shank. High-precision, max centring of drill bits with the highest torque.
DIN 2080 shank, internally threaded end.
Type
1
2
3
4
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
ISO 50 M24
ISO 50 M24
Chuck drive "B" K1
B12
B16
B16
B18
Height L
mm
22
22
25
25
1560GAM
Each
114,00
114,00
180,00
180,00
vuoto
DIN 2080CONNECTIONFORCHUCKSDRILLSHOLDER
DIN 69871/A ER PINCERS HOLDER CHUCKS WITH LOCKING COLLAR
1560GB
Prod. SCU
For ER-DIN 6499/ISO 15488 wide opening collets. High-precision, max centring of tools such as
milling cutters, drill bits, countersinks, reamers, boring bars, with the highest torque.
DIN 69871/A shank, internally threaded end.
Type
0
1
2
3
4
Shape/ thread K/G
ISO 40 M16 ISO 30 M12 ISO 40 M16 ISO 40 M16 ISO 50 M24
Tightening capacity Ø d mm 1-10
2-20
2-20
3-25
3-25
Height L
mm 70
63
72
80
100
Height d1
mm 32
50
50
63
63
For pliers Art.
1506GS-
1561GC
1560 GZ-
1561 GN
1560 GZ-
1561 GN
1561 GR 1561 GR
1560GB
Each 146,00
98,10
107,00
117,00
206,00
Hook spanners for DIN 6499 locking collars see Art. 840 GE-L.
vuoto
DIN 69871/AERPINCERSHOLDERCHUCKSWITHLOCKINGCOLLAR
DIN 69871/A MILLING CUTTER HOLDER CHUCKS WELDON MODEL
1560GBC
Prod. SCU
For milling cutters with Weldon shank. High-precision, max centring of milling cutters with the
highest torque.
DIN 69871/A shank, internally threaded end.
d mills drive Ø
mm
6
8
10
12
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
ISO 40 M16
ISO 40 M16
Height L
mm
50
50
50
50
Height d1
mm
25
28
35
42
1560GBC
Each
134,00
134,00
134,00
134,00
d mills drive Ø
mm
16
20
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
Height L
mm
63
63
Height d1
mm
48
50
1560GBC
Each
134,00
134,00
Sizes mm 10,12, 16 and 20 are running out of stock
vuoto
DIN 69871/AMILLINGCUTTERHOLDERCHUCKSWELDONMODEL
DIN 69871/A MILLING CUTTER HOLDER CHUCKS WITH FIXED DRAGGING
1560GBE
Prod. SCU
For milling cutters with hole connection. High-precision, max centring of milling cutters with the
highest torque.
DIN 69871/A shank, internally threaded end.
d mills bore Ø
mm
16
22
27
32
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
ISO 40 M16
ISO 40 M16
Height L
mm
17
19
21
24
Height L1
mm
60
58
58
58
Height d1
mm
39
48
48
60
1560GBE
Each
107,00
107,00
107,00
107,00
For cross-shaped clamping wrenches see Art. 911 GP.
