1289 / 1410
1289
Prices in EURO - VAT not included
1289
PLANING AND TURNING TOOL HOLDERS
13
PLANING AND TURNING TOOL HOLDERS
9708G
Orig. Hufnagel
Treated steel body. Heavy execution. Patented locking system.
HSS-E Cobalt 10% bars, square section, hardened and ground.
"Orkan-S" quality (W 9% - Co 10% - Mo 3.5).
Straight tool holder with bar.
Size K
6
12
Toolholder lenght
mm 125
240
Toolholder section
mm 18x12 35x25
Bar dimensions
mm 6x63 12x125
Height from base to cutting edge mm 15
29
9708G
Each 228,00 475,00
Product running out of stock
vuoto
PLANINGANDTURNINGTOOLHOLDERS
9710G
HSS-E
“Orkan-S" bars, hardness HRC 65-67. For Art. 9708 G.
Size K
12
Bar dimensions
mm 12x125
9710G
Each 45,10
Product running out of stock
vuoto
PLANINGANDTURNINGTOOLHOLDERS
TURNING TOOL HOLDERS
9711G
new
Prod. SCU
Hardened steel body. Right execution. 3° positive cutting angle. Toolholder without bar.
For bars of any length see Art. 9688 in the sections below.
Size
mm
6
8
10
12
16
Toolholder lenght
mm 125
145
165
180
210
Toolholder section
mm 11x18
12,5x20
14x26
16x30
20x32
Square bars section
mm 6x6
8x8
10x10
12x12
16x16
Height from base to cutting edge mm 14
16
20
23
28
9711G
Each 102,00
113,00
139,00
156,00
175,00
vuoto
TURNINGTOOLHOLDERS
CUTTING TOOL HOLDERS
9712G
new
Prod. SCU
Hardened steel body. Right execution. Toolholder without bar.
For bars see Art. 9712 GA.
Size
1
2
3
Toolholder lenght
mm 125
150
150
Toolholder section
mm 16/19x24 17/21x27,5 17/22x33
Bar dimensions
mm 12x3x2,2
14,5x4x3
17,5x5x4
Height from base to cutting edge mm 16
20
25
9712G
Each 74,50
96,40
128,00
vuoto
CUTTINGTOOLHOLDERS
9712GA
new
HSS-E
HSS-E Cobalt 10% bars, HRC 66. For Art. 9712 G.
Size
1
2
3
Bar dimensions
mm 125x12x3/2,2 150x14,5x4/3 150x17,5x5/4
9712GA
Each 43,80
46,50
56,10
vuoto
CUTTINGTOOLHOLDERS
TURNING OFF TOOL HOLDERS
9716G
Prod. SCU
Treated steel body.
Safe locking system.
Tool holder without bar.
For bars see Art. 9717 G.
Size
1
2
3
Bar dimensions
mm 75x8x2/1,5 100x10x2,5/2 125x12x3,5/3
Height from base to cutting edge mm 12
14
16
Toolholder lenght
mm 100
125
160
Toolholder section
mm 16x11
18x11
22x12
9716G
Each 52,40
66,90
73,60
vuoto
TURNINGOFFTOOLHOLDERS
9717G
HSS-E
Bars in HSS-E 10% cobalt steel, hardness HRC 66. For Art. 9716 G.
Size
1
2
3
Bar dimensions
mm 75x8x2/1,5 100x10x2,5/2 125x12x2,5/3
9717G
Each 25,70
30,70
41,80
vuoto
TURNINGOFFTOOLHOLDERS
