TOOL HOLDERS AND BARS FOR INSIDE USE
13
TOOL HOLDERS AND BARS FOR INSIDE USE
9720G
Orig. Hufnagel
Tool holder.
Treated steel, for bars Art. 9721 G to 9725 G.
Without bar.
Overall length
mm
120
For bars Gr.
BN 5-7-10-13-16
Section
mm 16x16
Cut height
mm
8
9720G
Each
49,70
Product running out of stock
vuoto
TOOLHOLDERSANDBARSFOR INSIDEUSE
9721G
HSS-E
Bars for Art. 9720 G.
HSS-E Cobalt 10%, “Orkan-S" quality
(W 9% - Co 10% - Mo 3.5). Hardness HRC 65-67.
Particularly used on universal milling machines, revolver and automatic lathes.
Once the head is worn out, they may be used as normal round bars.
Bars for roughing
Size BN
5
10
16
Overall length
mm 60
65
100
Drive length
mm 35
45
78
Drive Ø
mm 8
8
10
For bore by Ø min
mm 5
10
16
9721G
Each 48,70 56,60 93,50
Product running out of stock
vuoto
TOOLHOLDERSANDBARSFOR INSIDEUSE
9724G
60
HSS-E
Product description as Art. 9721G
Bars for 60° Metric thread.
Size BN
13
16
Overall length
mm 75
100
Drive length
mm 42
78
Drive Ø
mm 10
10
For bore by Ø min
mm 13
16
9724G
Each 73,30 98,20
Product running out of stock
vuoto
TOOLHOLDERSANDBARSFOR INSIDEUSE
TOOL HOLDERS FOR INSIDE USE
9728G
Orig. Hufnagel
For internal turning and threading.
Treated steel body.
Ground hardened shank.
Ground and hardened blades, HSS-E Cobalt 10%.
"Orkan-S" quality (W 9% - Co 10% - Mo 3.5). Hardness HRC 65-67.
Also HARD METAL blades, universal quality.
Tool holder without shank and without blades.
Size PB
12
15
20
28
Iron rest overall length
mm 110
130
150
180
Iron rest section
mm 24x20
31x28
37x32
53x50
Stem length and Ø
mm 200x12
250x15
300x20
500x28
For bore by Ø min
mm 16
22
29
38
Blades length
mm 15
20
26
36
Height from base to cutting edge mm 13,5/15,5 16,5/20,5
21/24
30/33
9728G
Each 78,40
81,50
132,00
204,00
Product running out of stock
vuoto
TOOLHOLDERSFOR INSIDEUSE
9729G
Product description as Art. 9728G
Straight shank without blades for Art. 9728 G.
Size PB
20
28
Iron rest overall length
mm 150
180
Iron rest section
mm 37x32
53x50
Stem length and Ø
mm 300x20
500x28
For bore by Ø min
mm 29
38
Blades length
mm 26
36
Height from base to cutting edge mm 21/24
30/33
9729G
Each 123,00
194,00
Product running out of stock
vuoto
